Lorex VQ1636HR Quick Setup Manual

4. Camera Specifications
Specifications:
Image Sensor 1/3" Hi-Res Color CCD
Format / # Pixels NTSC: 768(H) x 494 (V)
Horizontal Resolution 480 TV Lines
Scan System 2:1 Interlace
Sync. System Internal
S/N Ratio More than 48dB
Iris AES
AES ShutterSpeed 1/60 ~ 1/10,000 sec.
Minimum Illumination 0.1LUX (w/o LED)
0 LUX (w/LED)
IR Range Up to 60ft. (18.3m);14 LEDs
Video Output Comp. 1.0 Vpp @ 75ohm
Lens 4~9mm F1.6 / Varifocal
FOV (Diagonal) 35~70 Degrees
Video: BNC Female
Termination
Power: Barrel Female
Power Requirement 12V DC
Power Consumption Max 300 mA @ DC 12V
Operating Temp 14°F ~ 113°F
(-10°C ~ 45°C)
Dimension DIA: 4.8" (120mm)
H: 4.0" (100mm)
1.9 lb. / 880g
Weight
It's all on the web
Specification Sheets
Product Information
Software Upgrades
User Manuals
Firmware Upgrades
Quick Start Guides
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2007 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
VANDAL RESISTANT
WEATHERPROOF
VARIFOCAL DAY/NIGHT
IR DOME CAMERA
Model: VQ1636HR
Quick Set-up Guide
