Lorex CVC2032 Specifications

POLYCARBONATE DOME CAMERA
F E A T U R E S
• Polycarbonate housing provides high impact protection
against possible vandalism
• Smoked camera housing provides unobtrusive appearance
• 1/3" CCD B&W image sensor with polycarbonate dome housing
• Rotate camera 360° and/or Tilt camera 90° for optimal angle selection
• Built-in automatic back light compensation
• Includes: 1/3" CCD B&W Dome Camera, Polycarbonate Dome
Housing, extension cable, regulated 12V DC power supply
and RCA/BNC connector.
CVC2032
Strategic Vista International Inc.
300 Alden Road, Markham, 3700 Koppers Street, Suite 100
Ontario L3R 4C1 Baltimore, Maryland 21227,
Canada. USA.
B U S I N E S S A N D H O M E S E C U R I T Y
1/3" CCD B&W
S P E C I F I C A T I O N S
Image Sensor: 1/3" Interline transfer type B&W CCD
Effective Pixels: 510H x 492V (250K)
Scanning System: 525 Lines 2:1 Interlace
Scanning Frequency: 15.734KHz (H), 59.94Hz (V)
Resolution: 380 TV-Lines
Shutter Speed: 1/60 ~ 1/100,000 sec.
S/N Ratio: More than 48dB (AGC off)
Sync. System: Internal
Min. Illumination: 0.5 LUX (F2.0)
Gain Control: Automatic
Video Output: 1.0 Vp-p (75Ω load)
Lens: Fixed (3.6mm)
Power Supply: DC12V ± 10%
Power Consumption: <100mA (DC12V)
Operating Temp: -10 to +45 C / 14 to 113F
Operating Humidity: 90% RH Max.
Diameter: 125mm
S E E W H AT Y O U ' V E B E E N M I S S I N G
www.strategicvista. com
As our product is subject to continuous improvement,
SVII & subsidiaries reserve the right to modify product
design, specifications & prices without notice and without
©2005 Strategic Vista International Inc.
incurring any obligation. E&OE
