GB
Thank you for purchasing this product. Please read user guide for safety and
operations information before using the product. Keep this manual for future
reference. This product can create perfect laser programs and effects since it has
GREEN ANIMATION LASER
passed a series of strictly tests before delivery. Please check the attachments
EFFET LASER VERT
listed on the page after opening the carton. In the event of carton damage or
attachment missing in transit, please contact your dealer or our after sales service
department.
Features
The laser light source has a long life time and high stability and complies with the
international standards.
Laser effect: There are 25 patterns ( with 12 graphic patterns ) that can be used for
text display, graphic animations, laser beam, spatial projection and animation
effects.
Technical specifications
Voltage: ............................................................................ AC200-240V, 50Hz
Power consumption: ................................................................................. 10W
Laser wave length: ................................................................................ 532nm
Laser power: ........................................................................................ 100mW
Patterns: ........................................................... 25 ( with 12 graphic patterns )
Scanning angle: ......................................................................................... ±25°
Scanner:
...................................................................... Low noise step motors
Control mode: ........................................................ sound control / auto / DMX
DMX channel: ................................................................................. 8 channels
Dimensions: ............................................................... 160x150x12mm
Ref.: GREEN-100 (15-1790)
Net weight: .............................................................................................. 1.7kg
For indoor use only
USER'S MANUAL
MANUEL D'UTILISATION
3B
©Copyright Lotronic 2012
GREEN-100
1
Advertisement
Related Manuals for afx light GREEN-100
Summary of Contents for afx light GREEN-100
- Page 1 Scanner: ..............Low noise step motors Control mode: ............sound control / auto / DMX DMX channel: ................. 8 channels Dimensions: ……………………………………………………… 160x150x12mm Ref.: GREEN-100 (15-1790) Net weight: ....................1.7kg For indoor use only USER’S MANUAL MANUEL D’UTILISATION ©Copyright Lotronic 2012...
- Page 2 This control is used to adjust sensitivity of 1. Install the units in a suitable position (laying or appending). mic when you use GREEN-100 in sound 2. Use standard XLR microphone cable chain your units together via the XLR mode connector on the rear of the units.
-
Page 3: Manuel D'utilisation
Dimensions : ………………………………………………………160x150x12mm Poids net : ....................1.7kg Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities or your dealer about the way to proceed. ©Copyright Lotronic 2012 GREEN-100... - Page 4 La température de fonctionnement est de 18-30°C. alimentation pour alimenter un autre laser Nettoyez régulièrement la lentille extérieure avec un chiffon propre pour retirer GREEN-100 la poussière accumulée et optimiser la puissance lumineuse. ENTREE / SORTIE DMX Remplacez le fusible uniquement par un neuf en tous points identique au Connectez sur l’entrée DMX votre contrôleur...
-
Page 5: Canaux Dmx
NOTE IMPORTANTE : Les produits électriques ne doivent pas être mis au rebut avec les ordures ménagères. Veuillez les faire recycler là où il existe des centres pour cela. Consultez les autorités locales ou votre revendeur sur la façon de les recycler. ©Copyright Lotronic 2012 GREEN-100...
