Model CR3001 with parallel interface
NOTE: The parallel interface cash drawer does not come with
an interface cable. Any standard centronic parallel
printer cable may be purchased to interface between the
computer and the cash drawer.
1. Remove the cash drawer from its shipping container.
2. Remove the keys from its plastic bag.
3. Connect a parallel interface cable between the parallel port on
the computer and the "Parallel Input From Computer" connector
on the cash drawer.
4. Connect the power adapter output to the "Power Input From
Adapter" connector on the cash drawer.

FUNCTIONAL TEST

The following test sequence will verify that your cash drawer is
working properly. Before you start this procedure, you must install
the cash drawer correctly as outlined in the installation section
NOTE: The actual key entries are enclosed within
quotation marks (" "). Do not type the quotation
marks as part of your entry.
Model CR3000, CR3001 with dedicated interface:
1. From the C prompt type "MODE COM1 96,N,8,2" and press
ENTER.
2. Type "TYPE CON>COM1" and press ENTER.
3. Type any alphanumeric character(s) and press ENTER. The
cash drawer will open.
4. To return to the C prompt press and hold the CTRL key while
depressing the letter C.
