Summary of Contents for Logic Controls CR3002
- Page 2 NOTICE The manufacturer of the POS cash drawer makes no representations or warranties, either expressed or implied, by or with respect to anything in this manual, and shall not be liable for any implied warranties of fitness for a particular purpose or for any indirect, special or consequential damages.
- Page 3 TABLE OF CONTENTS FEATURES... 1 CARTON CONTENTS...2 INTERFACE DESCRIPTION ...2 INSTALLATION...3 FUNCTIONAL TEST ...…3 KEY LOCK OPERATION ...…3 CONNECTOR PIN OUT ..4 CONTROLLER BOARD JUMPERS ..4...
- Page 4 3. Two keys 4. This User’s manual INTERFACE DESCRIPTION Model CR3002 Connect the drawer to the computer 9 pin commnication port. Whenever the POS application software sends a bell (07 Hex) Command to the communincations port, the drawer will be opened.
- Page 5 INSTALLATION Your cash drawer has been pre-assembled to make the installation as simple as possible. Model CR3002 1. Remove the cash drawer from its shipping container. 2. Remove the keys and interface cable from its plastic bag. 3. Connect the DB9 connector of the interface cable to the computer COM1(or COM2) port.
- Page 6 The cash drawer is manually opened when the lock is in the full clockwise position. Model CR3002 Keylock Operation: : Drawer securely locked. Can not be opened by computer or manually.
- Page 7 MECHANICAL: Weight 14.3 lb. Height 3.3 in. Width 15.7 in. Depth 16.1 in. ELECTRICAL: INPUT TO SOLENOID SERIAL INPUT CONNECTION PIN OUT (DB25M) - Serial Input From Computer Pin # Function No connection Receive data from computer Transmit data to computer RTS, Request To Send;...
