- Page 1 Long Island 1 Drawer Side Table FLOOR AREA 60min 2M x 2M APPROXIMATE ASSEMBLY TIME 2 PERSON ASSEMBLY REQUIRED ASSEMBLY SPACE REQUIRED ASSEMBLY TOOLS PHILLIPS SCREWDRIVER Flat Head screwdriver DO NOT USE POWER DRILL 1 / 13...
- Page 2 Long Island 1 Drawer Side Table Important Please read these instructions carefully before use and keep for future reference. • This product is intended for domestic use only and is not designed for commercial use. • Do not assemble/use this item if any components are missing or damaged. Please contact the retailer straight away.
-
Page 3: Assembly Tips
Long Island 1 Drawer Side Table Assembly Tips For larger items, please ensure that you have sufficient space and people (as indicated on page 1) to assemble your product safely. We recommend that, where possible, all items are assembled near to the area in which they will be placed in use, to avoid moving the product unnecessarily once assembled. - Page 4 Long Island 1 Drawer Side Table Tips before you start: QUICKFIT Tighten quickfit until shoulder is flush with panel. Do not overtighten or undertighten. CAM LOCK When fitting cam lock, ensure starting position is correct before you insert connecting quickfit. Quickfit head should be in the centre of the cam lock when the two panels are joined.
-
Page 5: Hardware List
Long Island 1 Drawer Side Table HARDWARE LIST Cam Bolt Cam Lock Screw Wooden Dowel Screw Handle Ax19 Bx19 Cx12 Anti-tip Bracket Screw Floor Pads Washer Screw Anchor L Shape for drawer Flat shape for side panel (Left) (Right) (Left) (Right) Slider Slider... - Page 6 Long Island 1 Drawer Side Table 6 / 13...
- Page 7 Basic Kitchen Cart Long Island 1 Drawer Side Table STEP 1 6 x C 1 x D Front Back Left 1 x E Right Back Back Front Front STEP 2 STEP 2 12 x A 7 / 13...
- Page 8 Basic Kitchen Cart Long Island 1 Drawer Side Table STEP 3 This is how a cam nut works ..The head of the cam bolt 6 x B goes into the open mouth of the cam nut. You then turn the cam nut so it tightens over the bolt.
- Page 9 Basic Kitchen Cart Long Island 1 Drawer Side Table STEP 5 5 x A STEP 2 STEP 6 This is how a cam nut works ..The head of the cam bolt 5 x B goes into the open mouth of the cam nut.
- Page 10 Basic Kitchen Cart Long Island 1 Drawer Side Table STEP 7 2 x A 2 x B 4 x H Note: Its important not to over-tighten screws on the drawer sides until all sides are aligned and the drawer base is inserted. Tighten screws fully once base is inserted correctly.
- Page 11 Basic Kitchen Cart Long Island 1 Drawer Side Table STEP 9 4 x C TURN BACK 1 x F Front Front 1 x G Front Right Back Back Left Back Back Front STEP 2 STEP 10 WARNING: ENSURE THAT WALL STRAP IS 1 x M ATTACHED TO AVOID SERIOUS INJURY To avoid any serious injury, this product has been...
- Page 12 Basic Kitchen Cart Long Island 1 Drawer Side Table STEP 11 1 x I 1 x L 1 x P wall WARNING Serious or fatal crushing can occur from furniture tip over. To help prevent tip over: • Install all tip over restraints provided with your product. •...
- Page 13 Long Island 1 Drawer Side Table Wall Mounting & Fixing Guide NOTE: Supplied wall plugs are only suitable for use in masonry walls. If you have any doubts about using the correct plug for your wall, please seek professional advice. Failure of the product due to using incorrect fixings is the responsibility of the installer.
-
Page 14: Warranty Certificate
Please note upon receiving your warranty claim, the supplier will send, via the post or email, a repair and refurbished goods or parts no ce. Please provide your email address and advise the supplier, if you wish to obtain a repair and refurbished goods or parts no ce via email. AFTER SALES SUPPORT EMAIL : cs@meubilair.com.au Product code: 203242-07... - Page 15 In the event of a product fault, please email the Customer Service team. Please ensure that you include the product details (as shown on the card) at hand so that we are able to respond as quickly and efficiently as possible. Meubilair Direct Imports PTY LTD Customer Service Email: cs@meubilair.com.au...
