Summary of Contents for K-Rain KRX6
- Page 1 User Manual WARRANTY...
- Page 2 Please be sure to read through all the instructions before attempting to use your controller Model no: KRX6 iOS is a trademark of Apple Inc. Android is a trademark of Google LLC. The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0...
-
Page 3: Table Of Contents
Overview Controls Key Features Installation 9V Battery Power Supply Installing Holman Home Adding your KRX6 to Holman Home Adding your KRX6 using EZ Mode Adding your KRX6 using AP Mode Field Wiring Mounting the Unit Controls KRX6 Home Screen Start Settings... -
Page 4: Overview
Overview Controls 1. MAIN DIAL 2. AP indicator 3. START button 4. STOP button Á Do not disassemble this product. There are no serviceable parts inside. Some internal components can run at elevated temperatures and touching these could cause burns 4 of 28... -
Page 5: Key Features
Overview Key Features L On-board MANUAL L Wi-Fi control with Holman Home via controls: START and STOP, including shut-off or android Android apple iOS ® ® with the MAIN DIAL L 6 ZONES can be added to the 3 START times L 1A 24VAC plug pack supply L Scheduling L M-205 fuse rated at 1A... -
Page 6: Installation
Installation 9V Battery 1. Open the controller housing door 2. Locate the 9V battery snap (b) 3. Connect a 9V battery to the snap (c) ® This may be located under the terminal cover. If needed, please remove the cover using the two tabs (a), feed the battery 4. -
Page 7: Power Supply
Installation Power Supply ® This unit can run off a 50Hz ® Output circuits should external transformer with be installed and an output of 24VAC 50Hz protected in accordance with wiring rules L Input: 24V AC 50Hz Output: Max 1 amp ®... -
Page 8: Installing Holman Home
Installation Installing Holman Home 1. Download Holman Home 4. Read our User Agreement to your mobile device and Privacy Policy via the apple App Store and tap AGREE if you or google-p Google Play wish to proceed 5. Follow the prompts to register a Holman Home account with your email address... -
Page 9: Adding Your Krx6 To Holman Home
Installation Adding your KRX6 to Holman Home 3. If your KRX6 appears 1. Before attempting to connect your KRX6 to in the DISCOVERING Holman Home, ensure: DEVICES... section (f), tap ADD (g) • 9V battery connected • Plug pack connected to power socket •... - Page 10 Installation Adding your KRX6 to Holman Home 4. In the following screen, tap ® Alternatively, to connect circle-p (h) next to your KRX6 without sharing location, tap MANUAL INPUT (j) 5. Enter the Wi-Fi NAME (k) and PASSWORD (l) of your Wi-Fi network...
- Page 11 Installation Adding your KRX6 to Holman Home ® On first use, the KRX6 ® It may take a few minutes for your KRX6 to add to interface will need a Holman Home; please moment to initialise (p) wait for the progress dial (n) to finish 6.
- Page 12 Installation Adding your KRX6 to Holman Home 8. Your KRX6 will now 7. Once initialisation is complete and the be shown on the KRX6 is connected, HOME screen under the KRX6 home screen ALL DEVICES (r) will display; tap chevron- (q)
-
Page 13: Adding Your Krx6 Using Ez Mode
Installation Adding your KRX6 using EZ Mode Á Follow these 2. In the instructions if K-RAIN PRODUCTS your KRX6 does menu, tap KRX6 (t) not appear in the previously mentioned DISCOVERING DEVICES... dialogue 1. In the ADD DEVICE menu, tap K-RAIN PRODUCTS (s) 3. -
Page 14: Adding Your Krx6 Using Ap Mode
Installation Adding your KRX6 using EZ Mode 4. Work through the following prompts in Holman Home to complete the EZ MODE connection process Adding your KRX6 using AP Mode 1. Ensure your smartphone mobile data is switched off before trying AP MODE 2. -
Page 15: Field Wiring
Installation Field Wiring Á Disconnect all 240VAC power before commencing any field wiring or solenoid valve connection ® Strip approx. 6mm of insulation and place under the loosened screw, tighten gently and check cable is firmly held 1. Connect one cable from the terminals to each solenoid valve 2. -
Page 16: Mounting The Unit
Installation Mounting the Unit ® The unit is an indoor 1. Drive a #8 screw into model and must not be the wall, leaving approx. exposed to rain or water 4mm exposed. Use a ingress, or direct sunlight toggle bolt or masonry plug if necessary L Install near a 240V AC outlet... -
Page 17: Controls
Controls KRX6 Home Screen ® Within the KRX6 interface, tap KRX6 home (a) ® This page displays info for your KRX6, including WATERING status (b), STARTS status (c), WATERING DELAY settings (d), and DEVICE status (e)–note the icon will turn red... -
Page 18: Start Settings
Controls Start Settings ® Within the KRX6 interface, tap STARTS in the main footer menu ® Tap the desired START (g) for the following settings: • ENABLE (h) • Set a START TIME (i) • WATERING ROSTER (j) • Activate a ZONE using the check box square-c (k) •... -
Page 19: Zone Settings
Controls Zone Settings ® Within the KRX6 interface, tap ZONES (m) ® Tap the desired ZONE for the following settings: • ZONE NAME (o) • WATERING DELAY on or off (p) ® Also includes MISTING: • WATERING MODE (q) • ON TIME (r) •... -
Page 20: Manual Watering
Controls Manual Watering ® Within the KRX6 interface, tap MANUAL (u) ® Use the selector circle-d (v) to select a START to water ® Tap START play (x) to begin watering the as per the pre-set START settings ® Tap STOP stop (y) to end the watering session ®... - Page 21 Controls Manual Watering ® If your KRX6 is already watering a schedule, you will need to stop this to be able to water manually ® If multiple ZONES are selected they will water sequentially starting at ZONE 1 ® ZONES will run as NORMAL or MISTING watering depending on pre-set ZONE settings ®...
-
Page 22: Additional Notes
Offline Device ® A warning message (a) will be displayed if your KRX6 is not connected to the internet ® If your KRX6 still has a connection to power, it will still water the saved STARTS despite being offline from Holman Home–it... -
Page 23: Holman Home Automations
® If STARTS are run as part of a Holman Home automation, they will behave the same as a manually run START ® WATERING DELAYS only effect scheduled STARTS from the KRX6 interface–STARTS running from Holman Home automations will ignore WATERING DELAYS ® To exclude ZONES using the WATERING DELAY function, this will need to be set using two Holman Home automations–for example:... -
Page 24: Troubleshooting
11. Make sure that the Wi-Fi router has the DHCP service enabled. If it is not enabled, the address will be occupied. 12. Your Wi-Fi router may not compatible with your KRX6. It is recommended that you replace the Wi-Fi router and try again... - Page 25 This indicates a lack of Wi-Fi signal. You will need to not connecting move your KRX6 and Wi-Fi router closer to each other after mounting in desired position This indicates that there is no power to the unit. Your controller will not operate if there is an AC fault.
- Page 26 If the same outputs are still locked on, please contact our Customer Service team KRX6 is not connecting in Ensure mobile data is switched off AP MODE...
-
Page 27: Warranty
Warranty 3 Year Replacement Guarantee Holman Industries offers a 3 year To the extent permitted by law, this Holman replacement guarantee with this product. Replacement Guarantee excludes liability for consequential loss or any other loss or damage caused to property of persons arising In Australia our goods come with guarantees from any cause whatsoever. - Page 28 This will ensure we have a copy of your purchase and activate an extended warranty. Keep up to date to with relevant product information and special offers available through our newsletter. Scan here, or visit k-rain.com.au/register for more info...
