Hillsdale Furniture Snyder 103841-114283 Quick Start Manual

Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to insure that all components are
in proper posi�on, �ght and free from damage. Keep this assembly instruc�on for future reference. Adult assembly is required. The product of Hillsdale Furniture,
LLC is designed for residen�al use only. Customer Service Phone Number: 502-562-0000
CODE QTY
1 2 Headless Bolts
2 6 Allen Bolts M6x45mm
3 4 Allen Bolts M6x60mm
4 10 Ø13mm Spring Washers
5 10 Ø18mm Flat Washers
6 4 M5x32mm Pan Head Wood Screws
7 2 Plastic Washers
8 1 Allen Wrench
B
C
CARE & MAINTENANCE: The touch of a so� cloth is all the maintenance the finish will ever need. Please do not use harsh or abrasive cleaners for polishing, as they may
cause damage to the finish. Periodic checks are recommended to make sure that all hardware is securely �ghtened.
Snyder Non Swivel Stool
Model #103841−114283 Counter Stool
Model #103841−114282 Barstool
HARDWARE
A
D
C
E
CODE QTY COMPONENTS
A 1 Back Frame
C 2 Front Legs (Le� & Right)
D
• Do not let any sharp objects touch or rub
the surface of the product.
• When assembling, do not let children play
around the working area.
• Please confirm all parts are correct before
star�ng the assembly process.
• Do not �ghten all bolts and screws
completely un�l the en�re unit has been
assembled and set up.
• Be careful if using power tools as they can
over �ghten screws and strip threads.
Date: 07-25-2017
Page 1 of 2
CODE QTY COMPONENTS
B 1 Seat Cushion
D 2 Back Legs (Le� & Right)
E 1 Stretcher Frame
WARNING
HDFKC
