L8542340
Rev. 03/03/00
Libro istruzioni
Operating instructions
Betriebsanleitung
Livret d'instructions
Libro de instrucciones
CENTRALINA A MICROPROCESSORE
CONTROL UNIT WITH MICROCONTROLLER
MIKROCONTROLLER-STEUERUNG
CENTRALE A MICROCONTRÔLEUR
CENTRALITA A MICROPROCESADOR
DA.2XS433
DA.2XSE433
DA.2XS306
UNIONE NAZIONALE COSTRUTTORI
AUTOMATISMI PER CANCELLI, PORTE,
UNI
EN ISO
9001
SERRANDE ED AFFINI
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Beninca DA.2XS433
Summary of Contents for Beninca DA.2XS433
- Page 1 L8542340 Rev. 03/03/00 CENTRALINA A MICROPROCESSORE CONTROL UNIT WITH MICROCONTROLLER MIKROCONTROLLER-STEUERUNG CENTRALE A MICROCONTRÔLEUR CENTRALITA A MICROPROCESADOR DA.2XS433 DA.2XSE433 DA.2XS306 EN ISO 9001 Libro istruzioni Operating instructions Betriebsanleitung UNIONE NAZIONALE COSTRUTTORI Livret d’instructions AUTOMATISMI PER CANCELLI, PORTE, Libro de instrucciones...
- Page 2 Hiermit erklaren wir, dass unser Produkt Nous déclarons par la présente que notre produit Por la presente declaramos que nuestro producto DA.2XS433 / DA.2XSE433 / DA.2XS306 è conforme alle seguenti disposizioni pertinenti: complies with the following relevant provisions: folgenden einschlagigen Bestimmungen entspricht:...
- Page 3 PROG MENU 250mA ELS. CODE TCA/ 1 Funz. P.P. 2 Ch. Aut. 3 Cond. 4 Prelamp. F1 6.3A B.E. 6.3A 16 17 COM. APRE CHIUDE INPUT ANT. 230VAC...
- Page 4 DA.2XS433/DA.2XSE433/DA.2XS306 control unit with microcontroller The control unit with microprocessor DA.2XS433/DA.2XSE433/DA.2XS306 can be used with motors having a power not exceeding 750W. Installation instructions. a) The electrical installation and functioning logic must comply with current standards. b) Keep the power cables (for the motor and power supply) away from the control cables (buttons, photo- cells, radio).
- Page 5 Programming the control unit Gain access to the programming mode of the control unit by pressing the MENU push-button. After the first pressure of the button the PGM LED, which is usually flashing, will feature a fixed light to indicate that the programming mode has been entered. Presetting the operating time (TL) When the PGM and the TL LED’s (first and second from top) are switched on simultaneously, the control unit is ready to store the operating time in memory.
- Page 6 AUTOMATISMI BENINCÀ Srl - Via Capitello, 45 - 36066 Sandrigo (VI) - Tel. 0444 751030 r.a. - Fax 0444 759728...
