Mounting & Installation
1) Remove the thermostat from its packaging.
2) Choose a mounting location so that the thermostat can
measure the temperature as accurately as possible.
- Mount the thermostat 1.5 metres above the floor level.
- Prevent direct exposure to sunlight or other heating /
cooling sources.
3) Use a philips screwdriver to loosen the screw on the bottom of
the thermostat to open the front housing.
4) Wire the thermostat according to the wiring diagram on page 6.
5) Screw the backplate onto a back box or directly to the surface.
6) Ensure the temperature sensor is free from obstruction. Close
the front housing and tighten the screw on the bottom of
the thermostat.
Note:
For side entry of the temperature sensor, please use breakout provided.
