Rear Panel Description

The rear panel of the MRX-4SEN2 Sensor Extender displays the following information:
1. DC 5V: Connect the supplied power adapter to this port, the Power LED
becomes solid blue when the device has received power.
2. Sensor Inputs: Connect the sensor's 3.5mm plug to an available port. The
following URC sensors, with their respective model numbers, are
compatible with the MRX-4SEN2:
■ Voltage Sensor SEN-VOLT
■ Video Sensor SEN-VID
■ Contact Closure Sensor SEN-CCLS
■ Light Sensor SEN-LITE
■ Current Sensor (Magnetic Field) SEN-CMF
■ Audio Sensor SEN-AUD
3. Ethernet: If a wired connection is needed, this port uses a standard Ethernet
(RJ-45) plug to communicate via the local area network (LAN).
1
To connect to Wi-Fi, an
initial Ethernet connection
must be made first.
