Total Control
Front Panel Description
The front panel of the MRX-4SEN2 Sensor Extender displays the following information:
1. Power LED: Indicates the device has power.
2. Status LED: Indicates three (3) possible states:
■ Green: Good signal strength.
■ Red: Poor signal strength.
■ Off: No connection.
3. Data LED: Indicates the device is transmitting IR data.
When connected via
Ethernet, the status LED
does not illuminate.
2
MRX-4SEN2
Owner's Manual
1
2
3
