1 Module Overview
Module
Variants
Chip Embedded
Flash
PSRAM
Dimensions
At the core of the modules is an ESP32-S3FN8, an Xtensa® 32-bit LX7 CPU that operates at up to 240 MHz.
You can power off the CPU and make use of the low-power co-processor to constantly monitor the peripherals
for changes or crossing of thresholds.
ESP32-S3FN8 integrates a rich set of peripherals including SPI, LCD, Camera interface, UART, I2C, I2S, remote
control, pulse counter, LED PWM, USB Serial/Jtag, MCPWM, SDIO host, GDMA, TWAI
with ISO 11898-1, i.e. CAN Specification 2.0), ADC, touch sensor, temperature sensor, timers and watchdogs,
as well as up to 45 GPIOs. It also includes a full-speed USB 1.1 On-The-Go (OTG) interface to enable USB
communication.
Note:
* For more information on ESP32-S3FN8, please refer to
Espressif Systems
Table 1: Ordering Information
ESP32-S3-MINI-1
ESP32-S3-MINI-1-N8
ESP32-S3FN8
8 MB (Quad SPI)
15.4 × 20.5 × 2.4
ESP32-S3 Series Datasheet
3
Submit Documentation Feedback
ESP32-S3-MINI-1U
ESP32-S3-MINI-1U-N8
0
15.4 × 15.4 × 2.4
®
controller (compatible
.
