Technical Data; Package Contents - eXact PipeCut Infinity Operating Instructions Manual

Exact PipeCut Infinity pipe saw
Voltage
Power
No-load speed
Blade diameter
Mounting bore
Range of use
Max. pipe wall, plastics and other soft materials
Max. Pipe wall 230V, steel, iron
Max. Pipe wall 120V, steel, iron
Protection class
Spindle lock
Speed preselection
Constant electronic control
Overload Protection
Reduced starting current
Recommended generator capacity
The values given are valid for nominal voltages [U] of 230 V. For lower voltage and models for specific countries, these values can vary.
Exact PipeCut Infinity
Package contents, please check that the package contains the following items:
1. Exact PipeCut System Shoulder Bags, 2pcs
2. Exact PipeCut Infinity motor unit with blade installed
3. Tensioner device
4. Tensioner device with crank
5. Attachment chain segments, for pipe outer diameter up to 1850mm:
2 m 2 pcs
1 m 1 pc
0,5 m 1pc
0,2 m 2pcs
0,1 m 1pc
6. Chain selection chart for different pipe outer dimensions
7. Operating instructions
8. Allen key 5 mm attached to saw
220 V– 240 V or 100 V–130 V, all 50–60Hz
2500 W– 220 V– 240 V or 15 А-100 V– 130 V
I (low) = 1900/min, II (high) = 2885 /min
140 mm (5.6"), 165 mm (6.50"), 180 mm (7.2"),190 mm (7.6")
62 mm (2.44")
460 mm – 3000 mm / 18"-120"
43 mm / 1.7"
20 mm / 0.78"
12 mm / 0.5"
⧈ / II
Yes
Yes
Yes
Yes
Yes
4,9kVA for 230V, 3kVA for 100 V-120V
pipe cutting systems
5
English
