Installation
C) Switch/Gauge LCS/2
D) Wiring harness to connect LCS/2 Com-
puter to relevant devices
E) Programming and diagnosis connector
F) Others elements represented in the diagram
are:
G) Programming Tester V05
Personal computer with Interface Kit V05 (in
alternative to Programming Tester V05)
H) TPS (Throttle position sensor)
I) Petrol injectors
L) Lambda sensor
M) Ignition coil
N) Battery
O) Gas solenoid
P) Pressure regulator
Q) Gas level sensor
R) Temperature sensor *(optional component
supplied separately from LCS/2)
The drawings shown in Fig. 1 and 2 concerning
the Lpg and Cng conversion system are indica-
tive; for specific situations concerning the electri-
cal connections, see paragraph 6.
3.
INSTALLATION OF COMPUTER LCS/2
(Fig. 3)
The Computer must be attached to the car chas-
sis inside the engine compartment according fol-
lowing instructions:
- remove the fuses located on the wiring before
installing the parts and replace them once instal-
lation has been completed;
- position the Computer away from sources of heat
(exhaust header, radiators, etc.), protected by
water and away from ignition high voltage wires;
- position the Computer with the connector side
facing down to prevent any water droplets from
penetrating inside the control unit through the
connectors.
4.
INSTALLATION OF THE LINEAR
ELECTRO-MECHANICAL ACTUATOR
(Fig. 4)
4.1 LOW-SPEED ACTUATOR (ATT-MIN)
The reducer with linear electro-mechanical actua-
tor must be positioned parallel to the direction of
movement of the vehicle.
Fit the male jack (marked by the RED terminal from
computer LCS/2) in the connector on the actuator.
For more details, refer to the STEP MOTOR re-
Installation and adjustament manual Lambda Control System/2
ducer installation instructions inside the reducer
pack.
4.2 MEDIUM-HIGH SPEED ACTUATOR
(ATT-MAX)
The Linear Electromechanical Actuator must be
installed preferably at the mixer inlet (in order to
optimise the cut-off function) or, in alternative, along
the gas hose or on the regulator outlet.
Insert the male pin coming from the LCS/2 com-
puter to the connector on the Actuator.
IMPORTANT: never position the Linear Electrome-
chanical Actuator with the motor facing down or in
such a way that oil deposits can penetrate inside
the motor.
5.
INSTALLATION AND OPERATION OF
SWITCH / GAUGE LCS/2 (Fig. 5)
Install the Switch / Gauge LCS/2 on the dashboard
according following possibilities:
- insert the Switch / Gauge LCS/2 in an existing
hole with suitable dimensions;
- insert the Switch / Gauge LCS/2 in the dashboard
after making a rectangular hole (about 25x38 mm)
with the LANDI RENZO cutting device for
switches;
- position the Switch / Gauge LCS/2 in the dash-
board by using the external support provided.
5.1 SWITCH / GAUGE LCS/2 OPERATION
EXPLANATION
A) gas / petrol selector
with 2 position and indication of used fuel by
mean of 2 leds (B) and (C);
B) green led
turned on: indicates the car is regularly running
on gas;
rapid flashing: indicates the stand by for the au-
tomatic change over during the starting (that is
always on petrol);
slow flashing: indicates the malfunctioning of
LCS/2 during gas operation (see par. 5.3).
C) yellow led
turned on: indicates the car is running on petrol.
D) led series
indicates the level of gas (divided into fourths)
present in the tank: the red led indicates the car
is running on reserve.
E) connector
connect the switch to the wires coming from the
LCS/2 Computer.
