Item #
Model #
96181
FSI 1151 E WLNT
96198
FSI 1182 E WEPS
96206
FSI 1163 E NICK
Be sure to read all instructions
before starting installation.
Estimated Assembly Time:
30 minutes
Tools Needed (not included)
. Drill with 3/16" drill bit
. Phillips screwdriver
. Level (recommended)
Care Instructions:
Clean with soft cloth only.
No abrasive cleaning agents.
Plastic Covering
Use and Care Guide
Café Rod
Tools needed for installation.
(Not Included)
Level
Pencil
(Recommended)
Rod with 1 Finials attached
2 Wall Brackets
28
Phillips
Screw Driver
Parts Included
nd
2
finial in the
bag
Remove Plastic Rod Cover
Remove plastic covering before installation.
Do not use sharp tools that can damage the rod
finish
Bracket installation.
(diagram 1.)
1. Using bracket as a guide, adjust to desired
height and mark location on wall for mounting
screws. (Wall anchors may not be necessary
for all applications.)
2. Remove bracket from wall. Drill pilot hole using
3/16" drill bit and insert wall anchors.
3. Attach bracket to wall using screws provided.
4. Repeat steps 1 to 3 for additional brackets.
Use level if necessary.
Placing Rod and Drapes on Brackets
(diagram 2.)
1. Remove 1 finial from rod section by turning
counter clock wise.
2. Slip draper over rod until end of rod is visible.
3. Place rod in bracket cradles as shown.
4. Screw both finials back on the rod.
-48
in
in
71.12cm - 121.92 cm
5/8
in
diameter 1
.58 cm
4 Screws 4 Anchors
