Item #
te te
1 002 563 371
Model # FG-SHL5PCFC
USE AND CARE GUIDE
BRIDEWELL 5PC FIREPIT CHAT SET
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this deep seating
set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products
available for your home improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection FG-SHL5PCFC
Summary of Contents for Home Decorators Collection FG-SHL5PCFC
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this deep seating set. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products...
-
Page 2: Table Of Contents
Table of Contents Hardware Included ..............4 Table of Contents ............2 Safety Information ............2 Chair Package Contents ............5 Warranty ................. 3 Assembly ............... 6 What is Covered ............... 3 Care and Cleaning ............8 What is Not Covered ..............3 Pre- Assembly ............... -
Page 3: Warranty
Residential use of this furniture is warranted for a seven (7) year limited warranty period for the frame construction. The warranty is valid from the date of purchase and applies only to the original purchaser. If your Home Decorators Collection outdoor furniture fails structurally during normal use (other than damage as a result of dropping or breaking a cast part) within seven (7) years of purchase, the manufacturer will repair or replace the frame at its discretion with the same or similar product if the original product is discontinued, at no charge. -
Page 4: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY It will take one or two people about 25 minutes to complete the assembly process. Assemble this product on a blanket or towel or other soft, non-abrasive surface to avoid scratching the finish. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 5: Chair Package Contents
Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Right Arm (When Sitting) Left Arm (When Sitting) Chair Seat Back Cross Bar U Support Bar Seat Cushion Back Cushion Pillow HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986 -3 4 6 0 for further assistance. -
Page 6: Assembly
Assembly ATTACHING THE BACK CROSS BAR AND THE U SUPPORT BAR TO THE RIGHT AND LEFT ARMS □ Loosely attach the Back Cross Bar (D) to the inside back of the Right and Left Arms (A&B) with Bolts (AA) through Lock Washers (GG) and Metal Washers (EE). - Page 7 Assembly (continued) COMPLETING THE ASSEMBLY □ Place the Seat Cushion (F), Back Cushion (G) and Pillow (H) on the chair. □ The chair is ready for your enjoyment. □ Repeat steps 1-3 to assemble the other chair. NOTE: Periodically check to make sure all bolts are tight after long periods of usage.
-
Page 8: Care And Cleaning
Care and Cleaning Clean the furniture frame with a wet towel using a mild soap and water solution. Dry completely with a soft towel. Clean the cushions and sling seat material with a mild solution of soap and water and hang cushions to drip dry completely. It is recommended that cushions be stored in a dry area during rain and if they are not in use and in direct sunlight. - Page 9 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use. HOMEDEPOT.COM/HOMEDECORATORS...
- Page 10 HOMEDEPOT.COM/HOMEDECORATORS We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fire pit. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
- Page 11 Table of Contents Table of Contents Assembly Safety information Operation – Gas Cylinder Installation Warranty Operation – Natural Gas Conversion What is Covered Operation – Leak Check Operation – Battery Installation and Lighting the Fire What is Not Covered Pre-Assembly Maintenance Planning Assembly Package Contents...
- Page 12 Safety Information (continued) IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1●NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable.
- Page 13 Safety Information (continued) IMPORTANT SAFETY INFORMATION -PROPANE LP GAS The LP-gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable.
- Page 14 Warranty 1 YEAR LIMITED WARRANTY WHAT IS COVERED Fire pits Burner, steel fire pit bowl, all mechanical parts and fittings to control panel and burner assembly, and all fire pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship. Rust is not covered.
- Page 15 Pre-Assembly PLANNING ASSEMBLY Please read this entire instruction manual before beginning assembly. Identify all parts packed in carton using the parts lists. Remove all protective materials. If any parts are missing or damaged, do not attempt to assemble. NOTE: Place parts on a nonabrasive surface to avoid scratching.
- Page 16 Assembly Placing the lava rocks in the burner pilot box □ Place the Lava Rock (C) around the burner, and then remove the label from the pilot box. □ A gas fire pit requires 13.2 lbs lava rock. NOTE DO NOT completely cover the burner element or block the pilot box with the lava rocks.
- Page 17 Operation – Gas Cylinder Installation Installing the gas cylinder Connecting the gas cylinder □ □ Open the door, place the gas cylinder into the Gas Cylinder Connect the regulator, screw the black handle clockwise to Support. tighten, turn the black handle counterclockwise to remove. The hose must point down.
- Page 18 Operation – Natural Gas Conversion Disconnecting the propane hose Replacing with the natural gas orifice □ Disconnect the propane hose from the gas valve. □ Replace the propane orifice with the natural gas orifice, screw the natural gas orifice with the bellows tightly, then connect and tighten the natural gas orifice with the inlet tube.
- Page 19 Stick and cover the conversion label onto the propane rating □ plate. Serial Number: Model Number: FG-SHL5PCFC-FP CAUTION: This appliance has been converted to use natural gas. Propane orifice dia2.09mm, natural gas orifice dia4.18mm. Rated Heat Input : 50,000 BTU/h...
- Page 20 Operation – Leak Check Safety Information Checking for leaks □ Always perform the leak test as described below before NOTE: Make sure control knob is OFF . lighting this appliance or each time the cylinder is connected for use. □ Do not smoke or allow other sources of ignition in the area □...
- Page 21 Operation – Battery Installation and Lighting the Fire Pit Battery Installation Lighting Instruction □ Make sure the control knob is in the “OFF” position. □ Push in the gas control knob slightly and turn to “OFF”. □ Unscrew the push button cap on the igniter module located on □...
- Page 22 Maintenance □ Air flow must be unobstructed. Keep ventilation openings, controls, burner, and circulating air passageways clean and clear the debris. Signs of possible blockage include the following: Gas odor with extreme yellow tipping of flame. Fire pit does NOT reach the desired temperature. Fire pit flame is excessively uneven.
- Page 23 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
