- Page 1 793-1155 Evolution pressure washers Original Manufacturer Instructions...
-
Page 2: Table Of Contents
Introduction This manual and any other literature supplied must be read fully prior to the initial operation of your machine and be stored for later use or for subsequent owners. Pay particular attention to any instructions relating to operation and safety and maintenance of the unit. -
Page 3: Component Identification
1. Component Identification 1-11 1-10 Item No. Main Machine Photos Trolley Frame Trolley Baseplate on Anti-Vibration Rubbers Engine Gearbox Gearbox Oil Sight Glass High Presure Pump Throttle Control Lever Ignition Switch Battery 1-10 Engine Oil Dipstick 1-11 Engine Oil Filler (also 2-6) Item No. - Page 4 1. Component Identification continued E3T41200PLE, E3T30200PLE & E3T23250PLE Awaiting Photo E3T25300PLE E3T15500PLE, E3T18400PLE & E3T15400PLE Item No. Pump Close ups Unloader Valve Safety Valve Pulsation dampener (where fitted) Suction Filter Suction Filter Inlet Bypass Outet High Pressure Outlet...
- Page 5 1. Component Identification continued ACCESSORIES The version you receive will vary depending on the machine model specification. Item No. Accessories Suction Hose Assembly and Filter* Bypass Hose Assembly* High Pressure Hose Assembly* High Pressure Hose Inlet/Outlet Ports High Pressure Lance Assembly* Gun On/Off Trigger Trigger Gun Safetly Latch...
-
Page 6: Technical Specification
2. Technical Specification Model No. E3T41200PLE E3T30200PLE E3T23250PLE E3T25300PLE Engine Loncin LC2V80FD5 V-Twin, 4-stroke, OHV, forced air cooling Fuel Petrol Net Power 18.0kW @ 3600 Rpm in accordance with SAE J1349 Nominal Rpm Engine 3600 - Pump 1450 via 2.2:1 gearbox Starting Method Electric Start Fuel Tank... - Page 7 2. Technical Specification Model No. E3T15400PLE E3T18400PLE E3T15500PLE Engine Loncin LC2V80FD5 V-Twin, 4-stroke, OHV, forced air cooling Fuel Petrol Net Power 18.0kW @ 3600 Rpm in accordance with SAE J1349 Nominal Rpm Engine 3600 - Pump 1450 via 2.2:1 gearbox Starting Method Electric Start Fuel Tank...
-
Page 8: Intended And Proper Use - Commercial
3. Intended and Proper Use - Commercial This machine is intended for Commercial use and is not suitable for normal housekeeping purposes by private persons whereby there may be a source of danger to the public. The machine must be used solely by professional contractors who are properly trained and wearing protective clothing to the required health &... - Page 9 This machine has been designed for use only with cleaning agents approved by the manufacturer. The use of other cleaning agents or chemicals may adversely affect the safety of the machine. High pressure jets can be dangerous if subject to misuse. The jet must not be directed at persons, animals, live electrical equipment or the machine itself.
-
Page 10: Safety Devices
Risk of explosion! Do not put tools or similar on the battery, i.e. on the terminal poles and cell connectors. Risk of injury! Ensure that wounds never come into contact with lead. Always clean your hands after having worked with batteries. 5. -
Page 11: Pre-Operation Checks And Set Up
7. Pre-Operation Checks and Set Up CHECKS DAMAGE - Before each period of use ensure the machine and all components and accessories are complete and undamaged. Take care to ensure the suction hose and bypass hoses are kink-free. TRAVEL PLUGS - On the pump and gearbox REMOVE THE RED TRAVEL PLUGS and replace with the appropriate yellow-topped oil dipstick/breather Travel Plugs Travel Plugs... - Page 12 7. Pre-Operation Checks and Set Up continued CHECKS FUEL - Fill the fuel tank with petrol fuel, refer the engine manufacturers handbook for fuel types. DO NOT USE BIOFUEL TYRES - Ensure all four tyres are BATTERY - Connect the battery leads, inflated to 2 Bar (30 psi).
- Page 13 7. Pre-Operation Checks and Set Up continued SET UP Connect the suction filter and hose assembly to the suction filter hose barb. Ensure all connections are tight and leak free. Air leaks on the suction side will impair the machine performance and damage components.
-
Page 14: Start Up And Operation
7. Pre-Operation Checks and Set Up continued For twin outlet only - If using machine NOTE with two operators the rated flow will be split between each outlet. For example: If the machine has a rated flow of 30 Lpm each outlet will give 15 Lpm. -
Page 15: Stopping Procedure
8. Start Up and Operation continued Move the throttle lever to half revs. Pull out the choke if starting from cold. Turn the ignition switch clockwise. When engine runs smoothly, increase the revs as required. Push in the choke if used in step ... -
Page 16: Transporting
10. Transporting During transportation the machine must be secured using suitably rated straps and fixings. Ensure the fuel is turned off at the fuel tap. The machine must only be lifted and secured by attaching lifting/security equipment to the main frame. No lifting/security straps should come in to contact with the engine, gearbox, pump, valves or filter. -
Page 17: Loncin E3 Pressure Washer Maintenance Schedule
13. Loncin powered Evolution3 Pressure Washer Maintenance Schedule Each/ 3 months or 12 months or Activity First Use first 50 Hours 250 hours Inspect / top up oil levels Engine Gearbox Pump Change Oil Gearbox (SAE90 Gear Oil) Pump (SAE20/30 Pump Oil) Change Engine Oil Refer to Engine Manufacturer's handbook Water Suction Filter... -
Page 18: Troubleshooting
14. Troubleshooting Symptom Possible Cause Remedy Pump running normally Pressure Regulator valve Check and adjust but pressure low. Pump sucking air. Check water supply and possible air ingress. Nozzle badly worn Check and/or replace Worn piston packing Seek professional advice Fluctuating pressure Blocked water filter Check filter, clean or... -
Page 19: Warranty Information
EN60335-2-79-2012 EN1829-1-2010 EN1829-2-2008 EN4871-2009 Manufacturer Dual Pumps Ltd, Saxby Road Industrial Estate, Melton Mowbray, LE13 1BS. United Kingdom Person authorised to compile the technical file & declaration Tom Herridge, Director Signed – Date – 13/10/2020 We hereby declare that the machinery described above complies with the relevant basic health and safety requirements of the UKCA &... - Page 20 Unit 8, Hudson Road Saxby Road Ind. Est. Melton Mowbray Leicestershire LE13 1BS Telephone: +44 (0)1664 567226 Fax: +44 (0)1664 410127 E-mail: info@dualpumps.co.uk www.dualpumps.co.uk...
