Filterless, high efficiency, mono 3 w class-d audio amplifier

Advertisement

Quick Links

FEATURES
Filterless Class-D amplifier with ultraefficient spread-
spectrum Σ-Δ modulation
Internal modulator synchronization (SYNC)
3 W into 3 Ω load and 1.4 W into 8 Ω load at 5.0 V supply
with <1% total harmonic distortion (THD)
90% efficiency at 5.0 V, 1.4 W into 8 Ω speaker
Signal-to-noise ratio (SNR): 98 dB
Single-supply operation: 2.5 V to 5.5 V
Ultralow shutdown current: 20 nA
Short-circuit and thermal protection with autorecovery
Available in 9-ball, 1.5 mm × 1.5 mm WLCSP
Pop-and-click suppression
Built-in resistors reduce board component count
Default fixed 12 dB or user-adjustable gain setting
APPLICATIONS
