  • Page 1 USER MANUAL 48100E ESS Series LFP Battery Pack Version：01.00...
  • Page 2 Notice The products, services or features you purchase shall be bound by the commercial contract and terms. All or part of the products, services or features described in this document may not be in your purchase or within the scope of use. Unless otherwise agreed in the contract, we makes no express or implied statement or guarantee for the content of this document.

  • Page 3: Table Of Contents

    CONTENTS 1 Foreword..............................2 Safety................................ 2.1 Safety Precautions........................2.2 Abuse Operation......................... 3 Overview..............................3.1 Product Description........................3.1.1 Features..........................3.1.2 Basic Functions......................... 3.2 Application Scenario......................... 4 Application Description........................4.1 Parallel Connection Application.................... 4.2 Low-temperature Application....................4.3 Low battery-capacity Storage (SOC≤5%)................4.4 Application of Nearing the Ocean..................5 Product Introduction..........................

  • Page 4: Foreword

    1 Foreword Overview This user manual mainly introduces the 48100E ESS series product introduction, application description, installation instructions, power-on instructions, maintenance instructions and provides instructions for technical support engineers, maintenance engineers and users. Reader This document is mainly applicable to the following engineers...

  • Page 5: Safety

    2 Safety 2.1 Safety Precautions Before carrying out battery work, you must read carefully the safety precautions and master the correct installation and connection methods of the battery. Prohibit to turn it upside down, tilt, or collide. Prohibit to short-circuit the positive and negative poles of the battery, otherwise it will cause the battery to be damaged.

  • Page 6: Overview

    3 Overview 3.1 Product Description The 48100E ESS series products use lithium iron phosphate (LFP) as the positive electrode material. It can be widely used in energy storage systems such as residen- tial energy storage, back-up power, and PV self-consumption optimization.

  • Page 7: Application Scenario

    3 Overview • Parallel connection application Support multiple battery packs in parallel, RS485/CAN communication supports up to 6 groups without control unit（or max supports 15 groups with control unit）. • Balance function Support the cells balance function. • Extended function Extended SNMP V2, SNMP V3, LCD, anti-theft and the mixed use of lithium battery and lead-acid battery.

  • Page 8: Application Description

    4 Application Description 4.1 Parallel Connection Application The battery packs support parallel connection, and synchronously increases the backup time or backup power. Confirm the consistency between the battery packs, check the SOC and voltage and turn off the batteries before connecting them in parallel. Multiple battery packs of parallel connection need to use RS485/CAN to communicate, pay attention to the DIP switch settings.

  • Page 9: Application Of Nearing The Ocean

    4 Application Description days@25°C, 15 days@45°C. The battery needs to be recharged in time after storage, otherwise the battery may be damaged due to over-discharge, and the entire battery pack needs to be replaced. The following conditions may cause the battery pack to be stored in a discharged state: After the utility power failure, the line/fault cannot be eliminated in time, and the power supply cannot be restored for a long time.

  • Page 10: Product Introduction

    5 Product Introduction 5.1 Module Specification Parameter Introduction Dimension are defined as follows: Figure 5-1 Definition Diagram of Dimension Table 5-1 Product Specification Parameter List Nominal Dimension(mm) Charge Current(A) Nominal Reference Model Cell Qty Capacity Voltage(V) Weight(kg) Recommend (Ah) 445 450 132.5 48100E 51.2 445 450 132.5...

  • Page 11: Panel Introduction

    5 Product Introduction 5.2 Panel Introduction 5.2.1 Panel Function Figure 5-2 VT48100E Front Panel NOTE 48100E ESS series panel functions take 48100E as an example. The interface definition as below table： Table 5-2 Operation Panel Interface Definition Name Description Remark...

  • Page 12: Indicator Description

    5 Product Introduction NOTE The position of terminal block of the above-mentioned panel interfaces is different for different 48100E ESS series products. Please refer to the corresponding product datasheet. 5.2.2 Indicator Description There are 6 Indicators on the operation panel, divided into three categories: 4 green SOC Indicators, 1 red alarm Indicator and 1 green run indicator.

  • Page 13: Dip Address

    5 Product Introduction The corresponding relationship between battery operation status and indicator operation status is shown in the following table. Table 5-5 Battery Status and Indicator Operation Mode Battery Normal/ SOC Indicators Description status Abnormal Green Green Green Green Green Power off/ Sleep Flash mode...
  • Page 14 5 Product Introduction The relationship between DIP address and BMS address as below： Table 5-6 Correspondence between BMS and DIP Switch DIP 1 DIP 2 DIP 3 DIP 4 BMS Address...

  • Page 15: Communication Port Definition

    5 Product Introduction 5.2.4 Communication Port Definition RJ 45 definition as below： Table 5-7 RJ 45 Definition RJ 45Photo Description 1/2/3 1 2 3 4 5 6 7 8 RS485_A CAN _L CAN_H RS485_B NOTE The above is the definition of conventional communication，if you have special needs，please contact the authorized dealer.

  • Page 16: Installation

    6 Installation 6.1 Tools Preparation ATTENTION Use insulated tools to avoid electric shock. If you use tools without insulation protection, you need to wrap the exposed metal parts with insulation tape for insulation treatment. The following table describes the tools and meters that may be used before installation.

  • Page 17: Unpacking And Inspection

    6 Installation 6.2 Unpacking and Inspection Study this manual carefully before any installation of the batteries. The batteries must only be installed and operated by trained personnel. Check the quantity of battery and accessories with delivery list. Check the appearance whether there is damaged or leakage, if any damage is detected, please do not proceed to the next installation.

  • Page 18: Cable Connection

    6 Installation Figure 6-1Install the Battery Pack Figure 6-2 Battery Pack Grounding 6.5 Cable Connection 6.5.1 Cable Connection Use the negative power cable to connect the negative bus bar with the battery negative (‘-’) terminal, and use the positive power cable to connect the positive bus bar with the battery positive (‘+’) terminal.
  • Page 19 6 Installation B. If the battery total input/output current more than 100A in parallel, the wiring method should configure bus-bars to connect the power cables. Figure 6-4 Connect the Battery Pack Power Cable to Bus-bars 6.5.2 Communication Cable Connection A. Use the communication cable to connect the battery packs in series through the RS485/CAN communication port, and connect the battery packs at the end to the user's RS485/CAN communication port.

  • Page 20: Power On

    7 Power On B. Assign addresses to battery packs by dialing the dialing keys of the dialing switch. Please refer to the corresponding relationship between the DIP switch and the battery pack address. ATTENTION Wear safety protection equipment to prevent electric shock from causing electric shock injuries.

  • Page 21: Power System Parameter Setting

    Batteries will continue charge/discharge until BMS protection if there is communication fail or Lead-acid mode between battery and charger / Inverter. After 48100E ESS series batteries goes into the sleeping status, please turn on the Battery MCB/Switch against or press the reset button.

  • Page 22: Shipment & Maintenance & Storage

    8 Shipment & Maintenance & Storage 8.1 Shipment It is suitable for the transportation of vehicles, ships and airplanes. During transportation, shading, sun protection and civilized loading and unloading should be performed. The box containing the product is allowed to be transported by any means of transportation.

  • Page 23: Routine Maintenance

    8 Shipment & Maintenance & Storage 8.2.2 Routine Maintenance The staff should perform visual inspection on 48100E ESS series battery according to the inspection plan, please refer to the following table for maintenance. Table 8-1 Routine Maintenance（Every three-month） Items Standard...

  • Page 24: Battery Storage

    8 Shipment & Maintenance & Storage Table 8-2 Routine Maintenance（Every six-month） Items Standard Action Check whether happens alarm action, （Suggested） Have a complete charge & discharge and please check with the alarm list. Complete cycleunder the equipment no Please contact with Vestwoods if the Cycle lack of power.

  • Page 25: Trouble Shooting

    9 Trouble Shooting Please refer to the table below to deal with common faults： Table 9-1 FAQ Phenomenon Possible Cause Solution The power cable of the battery pack is not Reconnect the power cable of the battery pack properly connected. The indicator The power switch is off.

  • Page 26: Warranty

    10 Warranty Except for the following and the conditions specified in the contract, you can go to the authorized dealers for reasonable warranty and maintenance. 1 Failure of equipment caused by unauthorized disassembly and maintenance operations without the authorization of authorized dealers is not within the scope of the warranty.

  • Page 27: Abbreviations

    11 Abbreviations Battery Management System Depth Height Width Liquid Crystal Display LiFePO4 MOSFET Metal-Oxide-Semiconductor Field-Effect Transistor Negative Temperature Coefficient Personal Computer Printed Circuit Board Power Conversion System Remote Terminal Unit State of Charge...
