V-TAC V-T48160 Instruction Manual

Hide thumbs Also See for V-T48160:
Table of Contents

Advertisement

Quick Links

Download this manual
V-T48160
VTAC Volts
Instruction Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V-T48160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-TAC V-T48160

Summary of Contents for V-TAC V-T48160

  • Page 1 V-T48160 VTAC Volts Instruction Manual V1.0...

  • Page 4: Table Of Contents

    Catalog 1.Safety precautions ......... 1 1.1 General security .

  • Page 5: Safety Precautions

    1.Safety precautions 1.1 General security Statement When installing, operating and maintaining the equipment, please read this manual first and follow the signs on the equipment and all safety precautions . The “notice", "attention", "warning" and "danger" in the manual do not represent all safety precautions to be obser ved, but only supplement all safety precautions.
  • Page 6 ◆ When installing the equipment, use tools to tighten the screws. ◆ Paint scratches during equipment transportation and installation must be repaired in time. It is strictly prohibited to expose the scratched parts to the outdoor environment for a long time. ◆...
  • Page 7 ◆ Do not stand or lean on or sit on the equipment. ◆ Do not damage each module of the equipment. ◆ When installing the batter y module, if the batter y module falls or is strongly impacted, the equipment will be damaged. It is strictly prohibited to continue to use, other wise there will be safety risks (cell leakage, electric shock injur y, etc.).

  • Page 8: Personnel Requirements

    1.2 Personnel requirements ◆ The personnel responsible for the installation and maintenance of this equipment must understand various safety precautions and master the correct operation methods. ◆ Only qualified professionals or trained personnel are allowed to install, operate and maintain the equipment. ◆...

  • Page 9: Product Introduction

    ◆ If the equipment has multiple inputs, all inputs of the equipment shall be disconnected, and the equipment can be operated only after the equipment is completely powered off. Wiring requirements ◆ The use of the cable in high temperature environment may cause aging and damage of the insulating layer.

  • Page 10: Appearance Description

    2.2 Appearance description Description Functional Description Reset key On/OFF button Display connection address ADS Dialer 1/2 Normally open, closed during fault protection 3/4 Normally open, closed when a low batter y alarm signal has occurred RS485 RS485 communication interface CAN communication interface RS232 communication interface RS232 (for batter y condition monitoring)

  • Page 11: System Diagram

    2.3 System diagram (A) PV module (B) DC switch ( C) Inverter (D) AC switch (E) Power Distribution Box (H) Batter y(WALL) (F) Intelligent power collector (G) Power grid (J) WIFI (K) Router (I) GSM (M) APP (L) Bluetooth (N) Load Explanation ◆...

  • Page 12: Product Installation

    3.Product installation 3.1 Unpacking inspection Please confirm whether the outer package of the product is damaged before unpacking. After unpacking, please carefully check the product for damage or missing accessories. In case of damage or missing accessories, please contact the supplier directly for assistance.
  • Page 13 ◆ The installation location shall be reasonably away from the fire source. ◆ The installation location shall not be accessible by the children. ◆ The installation location shall be sufficiently away from water sources, such as water tap, sewer pipe, sprinkler etc., to avoid water infiltration. ◆...

  • Page 14: Ladder Use Safety

    3.3 Ladder use safety ◆ Wooden ladder or FRP ladder shall be used when power climbing operation may be involved. ◆ When using the herringbone ladder, the pulling rope must be firm, and someone must hold the ladder during operation. ◆...

  • Page 15: Electrical Connection

    ◆ Lock the nut and fix the batter y mounting bracket. Then hang the batter y on the mounting bracket. ◆ After adjusting the position of the batter y, lock the M6 * 40 screw at the top of the support, fix the batter y, and place the batter y to slide.

  • Page 16: Communication Line Connection

    Cable Length Description Terminal diameter Used for connection between Anderson/SC25-8 25mm² 1-3m batter y and inverter For batter y parallel connection Anderson 25mm² 1-3m 4.2 Communication line connection 4.2.1 RJ45 Communication point definition(8P8C) 1 2 3 4 5 6 7 8 RS485 RS485_B RS485_A...

  • Page 17: System Connection Diagram

    ◆ Different inverter communication protocols have different pin definitions. Please pay attention to the compatibility between the batter y and inverter CAN/RS485 communication line. 4.3 System connection diagram INVERTER PV combiner box AC_OUT AC_IN RS485 OR BAT+ RS485 OR CAN DC Breaker PV+ PV- BAT+ BAT-...

  • Page 18: Multiple Batteries In Parallel

    Description Description Cable color Cable color RJ45 Communication Line DC positive wire RS485/CAN communication DC negative wire RJ11 Communication Line 4.4.2 Multiple batteries in parallel INVERTER Batter y-1 AC_OUT AC_IN Batter y-2 RS485 OR BAT+ The power lines between each batter y are the same length Description Description Cable color...

  • Page 19: System Tuning

    ◆ The inverter only needs to communicate with the host (Pack1). ◆ When multiple batteries are connected with multiple inverters, it is best to connect through the combiner box. If it is not connected through the combiner box, the wiring mode shall be confirmed with the manufacturer's agent. And the cable from each batter y to the inverter remains the same length.

  • Page 20: Screen

    5.2.2 Screen HMI screen composition Home: Description ICON 0%<SOC<25% 25%=SOC<50% 50%=SOC<75% 75%=SOC=100% SOC=0% Batter y Alarm Status Batter y Information: Description Description Items Items Batter y Pack Address Env Temp Environment temperature Addr. Rem Cap Remnant capacity MOS Temp MOS Temperature Tol Cap Total capacity Batter y Cell Voltage...
  • Page 21 Batter y Information: Protection Status Description Description Items Items Discharge low temperature Short Circuit Protection DUTP protection Charge low temperature Discharge over current protection DOCP CUTP protection Discharge high temperature Charge over current protection COCP DOTP protection Charge high temperature Total under voltage protection TUVP COTP...

  • Page 22: Rst Key Description

    5.2.3 RST key description Description Mode BMS is in sleep state, press the key (3 ~ 6S) and release it, the protection Fault board is activated, and the LED indicator lights up successively from "run" for 0.5 seconds. BMS is in the active state. Press the key (3 ~ 6S) and release it, the protection Dormancy board is dormant, and the LED indicator lights up successively from the lowest power light for 0.5 seconds.

  • Page 23: Indication Description

    5.2.5 Indicator Description HMI Screen: There are 2LEDS on front panel to show the batter y working status. PACK Status Normal/Alarm/Protection Remark Sleep Power Off All off Standby state Normal Flash 1 Standby Cell low voltage Alarm Flash 1 Flash 3 The maximum power LED Normal flashes (flashes 2), and the...

  • Page 24: Wireless Kit(Optional)

    5.3 wireless kit(Optional) The wireless kit is divided into three modules: ◆ Bluetooth ◆ WIFI ◆ Each module is an independent module, which module can be confirmed by label. Outline drawing of wireless Kit Connecting wireless kit: ◆ Insert the module into the batter y wireless kit port, download the wireless kit app, and register the account after installation.
  • Page 25 User registration Switch to ”ME“ in the lower right corner of APP. ◆ Click the avatar position to register. ◆ “Language”for language switching, supporting 3 languages. Add device Click "home" in the lower left corner of the app to switch to the add product module. ◆...
  • Page 26 Alarm ◆ You can view batter y alarm related information. Description Description Items Items Discharge over current alarm MOS High temperature alarm MOS OT Low environment temperature Charge over current alarm alarm High environment temperature Total over discharge alarm alarm Discharge low temperature Total over charge alarm alarm...

  • Page 27: Batter Y Monitoring

    6.Batter y Monitoring 6.1 Software running environment The software runs on PC and it is compatible to use Windows operating system. The system environment requires the support of Microsoft .Net Framework version 2.0 or above. Please confirm that it has been installed before use. The installation is as follows: ◆...

  • Page 28: Interface Function

    ◆ Poor communication line or wrong wiring: Method: replace the communication line or correct the wrong wiring. ◆ The computer USB interface is not recognized: Method: change a USB interface ◆ Drive not installed: Method: install the driver corresponding to the communication line. Method for judging whether the communication line driver has been installed: ◆...
  • Page 29 Description Item Tr y connect Tr y to connect: search for available serial ports and open them. The data key, which is the package serial number, displays the package being read and presented on the current interface with white words on a blue background; Pack serial “Auto"...

  • Page 30: Parallel Monitoring

    ◆ Get administrator privileges: Enter the administrator password in the "administrator password" input box at the bottom right of the interface. After correctly entering the password, the input box turns green. At this time, you have obtained administrator permission. 6.3.2 Parallel monitoring ◆...

  • Page 31: Parameter Setting

    Pause / continue: when reading, click "pause" to read, and then click again to continue reading. Save record: save the record on the interface to local. Delete record: delete the storage record of BMS board. Explanation when reading, the prompt "no more data" indicates that the reading has been completed.

  • Page 32: System Setting

    Write parameters: over write BMS parameters. This operation requires administrator privileges. Restore default parameters: restore all parameters to the default parameters. The default parameters are from the preset parameters in BMS. This operation requires administrator privileges. Import parameters: read the data in the local file into this interface. Note: the data is only read on the interface and has not been written into the BMS.

  • Page 33: Replacing Inverter Protocol(Optional)

    6.4 Replacing inverter protocol on batter y monitoring(Optional) Software running environment This function can only be realized by installing the protocol conversion board. Before using this function, please confirm whether the protocol conversion board is installed on this batter y. This software does not need to be installed independently, but only needs to meet the environment.

  • Page 34: Maintenance And Requirements

    7.Maintenance and replacement ◆ Please maintain the equipment when you are familiar with and understand the contents of this manual and have appropriate tools and test devices. ◆ Before carr ying out maintenance work , please power down the equipment first, then follow the instructions of the delayed discharge label and wait for the corresponding time to ensure that the equipment has been powered down before operating the equipment.

  • Page 35: Warranty Products

    ◆ Batter y maintenance shall be performed or super vised by personnel familiar with the batter y and its required precautions. ◆ After the batter y production test is completed, it needs to be supplemented to 30-50% SOC at least before storage. 9.Warranty products Requirement: During the warranty period, the company requires customers to provide invoices and...
