Page 1: Surveying
Eavsion Unicom Map Survey User Mannual V1.1/2022.08 EAV-SUT30 SUZHOU EAVISION ROBOTIC TECHNOLOGIES CO., LTD Address: Unit 1-A, No.3 Workshop, 28 Xiasheng Road, SIP, Suzhou, China Website: www.eav.top Tel：4008002872... -
Page 2: Table Of Contents
Table of contents Surveying ....................................1 Disclaimer ....................................3 Precautions ..................................... 3 Product overview ..................................4 Surveying Structure ............................... 4 1. RTK antenna ................................4 2. Antenna cap ................................4 3. Surveying front cover ..............................4 4. surveying middle cover ..............................4 5. -
Page 3: Disclaimer
EAVISION shall not be borne by any loss or injury caused by non-use, modification or disassembly of the original parts. EAVISION shall not be liable for any consequences arising from the use of this product in violation of laws and regulations. -
Page 4: Product Overview
Product overview EA-SUT30 V1.0 is a product developed by Suzhou EAVISION Robotic Technology Co., Ltd. for the needs of high-precision map surveying and mapping. By receiving RTK signals, it helps users to achieve high-precision boundaries, area mapping and obstacle identification of operating plots. -
Page 5: Chcek List Before Use
Chcek List Before Use Visual inspection (1) Whether the RTK antenna is damaged (2) Check whether the casing is damaged, so as to prevent the circuit board from being damaged due to the entry of external water (3) Whether the sealing plug is tightly closed to prevent the circuit board from being damaged due to the entry of external water Power-on check (1) When the device is in the off state, after pressing the Power button (t>1.8s), the device will enter the... -
Page 6: Low Battery Indicator
low battery indicator (1) Working status: Low battery (estimated remaining usage time＜＝30min) ,Batt1 keeps flashing (on for 1s, off for 1s), and stops flashing when charging; (2) Off status: Low battery (estimated remaining usage time＜＝30min) ,Batt1 keeps flashing (on for 1s, off for 1s),within 3s of battery display keep flashing;... -
Page 7: Operation Steps
Operation steps Turn on the plotter Press and hold the power button of the plotter for 1.25s-2.25s to turn it on, and wait for the "wifi/BT" light of the plotter to be always on App pairing to connect to the mapper Open the "EA-SUT30 and Mapping"... - Page 8 Click the corresponding mapper name in the device list After successful pairing, the name of the plotter will be displayed on the top of the screen. And automatically connect to the cloud base station, you can click the cloud base station entrance in the upper left corner to check whether the connection is successful.
- Page 9 Select the required new plot Modify parcel information...
- Page 10 Waiting for the number of satellites>10, difference: normal, positioning accuracy: RTK. And "Record Boundary Points" is highlighted, you can start marking...
-
Page 11: Appendix
Appendix Product parameters Size 171*63*55mm(witout extension bar) Working hours ＞8H Surveying Waterproof rating IP65 parameters Extension rod 500mm*4 Weight 400g(without extension rod) Signal GPS/BDS/GLONASS Input voktage/frequency 100-240V~50/60hz Output voltage 5V-3A/9V-2A/12V-1.5A Warranty The scope of application of the "Three Guarantees" of the map corrector. Products subject to free warranty service must meet the following conditions: Normal use within the specified product warranty period;... - Page 12 Party A for repair or replacement matters, and the repair and replacement costs shall be determined by both parties through negotiation. In the case of the company launching other preferential sales policies, it shall be implemented in accordance with its specific provisions. ＦＣＣ Ｓｔａｔｅｍｅｎｔ ...
- Page 13 Repair Date Repairer Records Date Description Details Remarks: 1. This certificate must be stamped by the authorized sales unit of EAVISION Robotic Technologies to take effect. Co., Ltd. 2. For details, please refer to the Applicable detailed list of company guarantees.
- Page 14 Please Follow EAVISION Official Social Media Channel： YouTube，Facebook，Twitter，LinkedIn,Instagram The contents of this manual and product specifications are subject to change without prior notice. Suzhou EAVISION Robotic Technologies Co.,Ltd. Address: Unit1-A, No.3 Workshop, 28 Xiasheng Road, SIP, Suzhou, Jiangsu Province, China Website：www.eav.top...
