- Page 1 ROLLING HEAD PINSPOTTER ITEM# 27182 MACHINERY DIVISION OWNER’S OWNER’S ® MANUAL MANUAL...
-
Page 2: Table Of Contents
Trouble free service is the foundation on which all Duro Dyne Pinspotters are built. Proven solid state components located for easy access. Duro Dyne continues this concept and brings the RH Mach 70 Rolling Head to a new and higher level of reliability, serviceability and efficiency. -
Page 3: Parts Locator
PARTS LOCATION PARTS LOCATION 17391 Actuator Swival Bolt 17283 Trigger Actuator Assembly 17284 Trigger Actuator Switch 17291 Rear Bumper Stop 17278 Steel Track 44063 Lower Ground Bar 17191 Upper Weld Tip 17189 Upper Replacement Plates (5/pkg) 17192 Lower Weld Tip 18032 Lower Replacement Plates (5/pkg) 17376 Lower Mandrel... - Page 4 PARTS LOCATION PARTS LOCATION 44095 Track Sensor 39296 Vibrator Bowl 44088 Flex Link 39298 Vibrator Base 17264 Upper Track Side Rails 39273 Vibrator Base Plate 44086 Clip Pin Release Spring 44085 Clip Pin Release 44084 Locking Knob 17257 Vibrator Support Casting Catch 18056 Locking Knob 17265 Lower Track...
- Page 5 PARTS LOCATION PARTS LOCATION 39196 Vibrator Cord 44114 Vibrator Strain Relief 39068 Receiving Board 44130 Laser Control Board 18065 Vibrator Circuit Breaker (2 Amp) 18066 220V Phase Control Located Inside Control Console 44008 Upper Feed Track Casting 17288 Trigger Actuator Plug 44077 Weld Poteniometer 44031 Vibrator Potentiometer 17334 Head Test Switch...
- Page 6 PARTS LOCATION PARTS LOCATION TROLLEY TROLLEY...
- Page 7 PARTS LOCATION PARTS LOCATION LEFT LEG CONSOLE LEFT LEG CONSOLE...
- Page 8 PARTS LOCATION PARTS LOCATION 44067 Flexible Wire Mold 17327 Footswitch Receptacle 44089 Weld Cable-Long 44070 Weld Cable Lug Connector 44101Weld Transformer 9145 Line Cord with Strain Relief TRANSFORMER ENCLOSURE TRANSFORMER ENCLOSURE...
-
Page 10: Installation Instructions
NOTE: The Rolling Head Mach 70 Pinspotter has two redundant weld circuits. In the event that the solid state relay controlling the weld fails you may simply flip the switch to the other circuit and continue production. A replacement Weld Relay should then be ordered through your local Duro Dyne wholesaler. STARTING OPERATION 1) Never actuate the unit without metal over the mandrel or lower copper ground bar. -
Page 11: Maintenance
STARTING OPERATION (continued) Weld time is the length of time the welding transformers are on. A fraction of a second is generally all the time needed for a quality weld. Unnecessary weld time not only wastes energy but can also burn up the pins. -
Page 12: Notes
SERVICING A SIMPLIFIED STEP-BY-STEP PROCEDURE Duro Dyne has called upon its many years of pinspotting experience in designing the Mach 70 Rolling Head. Your unit has been rigorously factory tested and inspected to provide many years of dependable service. WHAT TO DO BEFORE YOU BEGIN TROUBLESHOOTING: CONSULT THE MANUAL. -
Page 13: Parts List
PARTS LIST PARTS LIST 09145 Line Cord w/ Strain Relief 17363 First pulse reed switch 17084 Air hose 3/8” natural 17364 Feed cylinder 17085 Male camlock 17372 Footswitch 17122 RH-IV 28-14 12-Position Terminal Block 17376 Lower Mandrel 17134 Universal Short Shaft Extension Kit 17377 Air regulator 17135... - Page 14 NOTES -14-...
- Page 15 NOTES -15-...
- Page 16 Please Visit Our Website www.durodyne.com for the most up to date product information. ® Duro Dyne, Bay Shore, NY 631-249-9000 • Fax: 631-249-8346 MACHINERY DIVISION Duro Dyne Midwest • Duro Dyne West • Duro Dyne Canada 10/28/2022 www.durodyne.com • E-mail: durodyne@durodyne.com BI027412...
