- Page 1 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com GBAC GBAC ROTO BONDER OTO BONDER WITH CIRCULATING SYSTEM MACHINERY DIVISION OWNER’S L to R Unit Shown MANUAL - -...
-
Page 2: Table Of Contents
2) Check and adjust the air supply every week. (See Maintenance Section.) 3) The GBAC is designed for use with genuine Duro Dyne water- based adhesives. IMPORTANT Always follow manufacturer's recommendations for proper safety and... -
Page 3: Parts Location
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com PUMP PARTS LOCATION 39172 39237 39238 Clean Up Switch Adjustment Knob Adjustment Handle Casting 39109 Power Light 17309 Power Switch 39239 Valve Chart 39236 Metering Wheel 17377 Air Regulator 39197 Multi-Port Valve (only) 39169... - Page 4 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com - -...
- Page 5 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com - -...
-
Page 6: Operation
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com Selector Knob Assembly Fig. A VALVE FUNCTION CHART Fig. C TURN SPECIFIED VALVE HANDLE TO APPROPRIATE POSITION TO FILL: DOWN Trough from Drum Storage Tank from Drum CIRCULATE: Trough from Storage Tank Trough to Trough (in-out) TO EMPTY: Trough to Storage Tank... -
Page 7: Clean-Up
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com Fig. A Fig. C Selector Knob Assembly VALVE FUNCTION CHART TURN SPECIFIED VALVE HANDLE TO APPROPRIATE POSITION TO FILL: DOWN Trough from Drum Storage Tank from Drum CIRCULATE: Trough from Storage Tank Trough to Trough (in-out) TO EMPTY: Trough to Storage Tank... -
Page 8: Maintenance
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com EXTENDED CLEAN-UP NOTE: If the machine is to be idle for several days there are additional clean-up procedures which must be followed. With power off remove the exit rack and metering bar. With a long handled brush wipe down the trough. At this time the trough should still contain water. -
Page 9: Electric System Servicing
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com ELECTRIC SYSTEM SERVICING It is necessary to use a voltmeter and an ohmmeter to perform the simple servicing procedures. Follow the instructions below for reading resis- MEASURING RESISTANCE (OHMMETER) tance and voltage. 1) Disconnect the power supply. - Page 10 H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com Fig. A VALVE FUNCTION CHART TURN SPECIFIED VALVE HANDLE TO APPROPRIATE POSITION TO FILL: DOWN Trough from Drum Storage Tank from Drum CIRCULATE: Trough from Storage Tank Trough to Trough (in-out) TO EMPTY: Trough to Storage Tank 1-2-3-4...
-
Page 11: Circulation System Servicing
H. WEISS MACHINERY & SUPPLY PHONE: (718) 605-0395 - www.hweiss.com CIRCULATION SYSTEM SERVICING The air is on but the adhesive is not circulating through the plumbing. NOTE: Never force a valve handle. If a valve handle sticks, remove the valve and soak it in warm water. Check the valve setting against the function chart to insure that the valves are set properly. -
Page 12: Parts Listing
Metering Shaft 39017 Manifold Gasket (2) 39216 Mitre Gear (Pr.) 39018 Pump Diaphragm Set (1) 39217 Metering Bushing 1/2 ID (3 set) 39218 Metering Collar ® MACHINERY DIVISION © 2008 Duro Dyne Corporation Printed in USA 09/2008 BI039405 - -...
