Power smart PS5040 Instruction Manual page 26

Engine parts list
Item Stock#
1 100011264-0003
2 100056645
3 100713739
4 100010181
5 100004419
6 100050881
7 100011260-0005
8 100007083
9 100050896
10 100073758
11 100713979
12 100004599
13 100002464-0001
14 100079792
15 100055588-0009
16 100010387
17 100009376
18 100061091
19 100078607
20 100122101
21 100078606
22 100127490
23 100050035
24 100051029-0002
25 100093486
26 100010947-0001
Description Qty.
Bolt, M6×16 7
Valve Cover 1
Breather Hose 1
Gasket, Valve
1
Cover
Rocker Arm
2
Assembly
Rocker Arm Base 1
Bolt, M6×10 3
Shroud 1
Valve Locker 4
Valve Spring Seat 2
Valve Spring 2
Intake Valve Seal 1
Bolt, M8×60 4
Cylinder Head 1
Bolt, M6×20 3
Stud, M8×34 2
Spark Plug 1
Stud, M6×98 2
Gasket,
Carburetor 1
Insulator
Insulator 1
Gasket,
1
Carburetor
Carburetor 1
Stepping Motor
1
Cover
Screw, M4×6 4
Stepping Motor 1
Screw, M4×12 2
Ite
Stock#
m
27 100030062
28 100033258
29 100052405
30 100005137
31 100017699
32 100005629
33 100098952
34 100099680
35 100005078
36 100004771
37 100087055
38 100004949
39 100011463-0002
40 100155656
41 100010558
42 100077152
43 100004262
44 100713981
45 100713980
46 100003243
47 100003221
48 100003123
49 100003086
50 100003446
51 100011319-0001
52 100128008
26
Description
Motor Base
Guide Clamp
Spring
Clamp
Fuel Hose
φ4×φ10×320
Gasket, Carburetor
Air Filter Assembly
Air Filter Base
Assembly
Air Filter Baffle
Air Filter Element
Air Filter Cover
Bolt
Nut, M6
Gasket, Cylinder Head
Pin, φ10×16
Push Rod
Tappet
Exhaust Valve
Intake Vavle
Piston Ring Set
Circlip
Piston Pin
Piston
Connecting Rod
Assembly
Bolt, M8×32
Crankcase Cover
Qty.
1
1
1
2
1
1
1
1
1
1
1
1
2
1
2
2
2
1
1
1
2
1
1
1
6
1
