- Page 1 Si011281E REMOVAL PROCEDURE S E R V I C E M A N U A L 5.0/6.0 kW Class Outdoor Unit Non-Inverter Pair Type...
- Page 2 Service Manual Removal Procedure Outdoor Unit Cooling Only RE50NRV16 RE60NRV16 REL50NRV16 REL60NRV16...
-
Page 3: Table Of Contents
Si011281E Table of Contents 1. Outer Panels ...................2 2. Outdoor Fan / Fan Motor.................3 3. Electrical Components ................5 4. Capillary Tube ..................8 5. Compressor ASSY ................10 Note: The illustrations may be slightly different depending on the model. Removal Procedure... -
Page 4: Outer Panels
Outer Panels Si011281E 1. Outer Panels Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the 4 screws Top panel and remove the top panel. Remove the 7 screws of the front panel. -
Page 5: Outdoor Fan / Fan Motor
Si011281E Outdoor Fan / Fan Motor 2. Outdoor Fan / Fan Motor Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Pull out the 2 terminals Fan motor capacitor (C2) Fan motor lead wire (red, white) from the fan motor capacitor (C2). - Page 6 Outdoor Fan / Fan Motor Si011281E Step Procedure Points Remove the screw and Be careful so as not to remove the fan motor damage the top part of the fixing plate. outdoor heat exchanger fins. When reassembling, put the fan motor lead wire through the back of the fan motor so as not to be entangled with the outdoor fan.
-
Page 7: Electrical Components
Si011281E Electrical Components 3. Electrical Components Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the right side The stop valve cover has 3 Stop valve cover panel. - Page 8 Electrical Components Si011281E Step Procedure Points Remove the 2 screws on the right side (lower). Remove the 3 screws on the rear side. (R18995) Unfasten the hook. (R18998) Remove the right side Right side panel panel. (R18996) The right side panel has 2 hooks at the bottom.
- Page 9 Si011281E Electrical Components Step Procedure Points 2. Remove the electrical Compressor motor capacitor Compressor motor capacitor component ASSY. (C1) Pull out all the 3 to terminal board terminals from the (2_upper): blue compressor motor capacitor (C1). to compressor (S): red to compressor (R): blue (R19011) Terminal board...
-
Page 10: Capillary Tube
Capillary Tube Si011281E 4. Capillary Tube Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. - Page 11 Si011281E Capillary Tube Step Procedure Points Remove the protection net. Protection net (R19002) Heat up the 2 brazed The design of capillary tube parts and remove the varies depending on the capillary tube. model. Capillary tube (R19003) Removal Procedure...
-
Page 12: Compressor Assy
Compressor ASSY Si011281E 5. Compressor ASSY Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. - Page 13 Si011281E Compressor ASSY Step Procedure Points Disconnect the Pattern 1 compressor lead wires. R(V) Compressor lead wire Remove the gasket. Gasket S(W) C(U) (R19014) S (W): red C (U): white R (V): blue Pattern 2 (R19005) Remove the 3 screws and remove the partition plate.
- Page 14 Compressor ASSY Si011281E Step Procedure Points Remove the 3 nuts of the compressor. Compressor (R19007) Heat up the brazed part of the discharge side and disconnect. Heat up the brazed part of the suction side and Suction side disconnect. Discharge Lift the compressor side ASSY up and remove it.
- Page 15 Revision History Month / Year Version Revised contents 06 / 2013 Si011281E First edition...
- Page 16 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
