OPERATION MANUAL
System air conditioner
RXYSQ4M7V3B
RXYSQ5M7V3B
RXYSQ6M7V3B
REYQ8M7W1B
REYQ10M7W1B
REYQ12M7W1B
REYQ14M7W1B
REYQ16M7W1B
REYQ18M7W1B
REYQ20M7W1B
REYQ22M7W1B
REYQ24M7W1B
REYQ26M7W1B
REYQ28M7W1B
REYQ30M7W1B
REYQ32M7W1B
REYQ34M7W1B
REYQ36M7W1B
REYQ38M7W1B
REYQ40M7W1B
REYQ42M7W1B
REYQ44M7W1B
REYQ46M7W1B
REYQ48M7W1B
and
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daikin RXQ5M7W1B
Summary of Contents for Daikin RXQ5M7W1B
-
Page 1: Operation Manual
OPERATION MANUAL System air conditioner RXQ5M7W1B RXQ5M9W1B RXYSQ4M7V3B RXQ8M8W1B RXQ8M9W1B RXYSQ5M7V3B RXQ10M8W1B RXQ10M9W1B RXYSQ6M7V3B RXYQ5M7W1B RXYQ5M9W1B RXYQ8M8W1B RXYQ8M9W1B REYQ8M7W1B RXYQ10M8W1B RXYQ10M9W1B REYQ10M7W1B RXYQ12M8W1B RXYQ12M9W1B REYQ12M7W1B RXYQ14M8W1B RXYQ14M9W1B REYQ14M7W1B RXYQ16M8W1B RXYQ16M9W1B REYQ16M7W1B RXYQ18M7W1B RXYQ18M9W1B REYQ18M7W1B RXYQ20M7W1B RXYQ20M9W1B REYQ20M7W1B RXYQ22M7W1B RXYQ22M9W1B REYQ22M7W1B... -
Page 2: Parts View
RXYSQ RXYQ REYQ UNIT NO. RXYSQ RXYQ Double-flow Multi-flow Corner Ceiling Suspended Wall Mounted REYQ... -
Page 3: Table Of Contents
flap is in operation. Fingers may become caught or the unit may break down. Thank you for purchasing this Daikin air conditioner. Never replace a fuse with that of wrong ampere ratings Carefully read this operation manual before using the air or other wires when a fuse blows out. - Page 4 Arrange the drain hose to ensure smooth drainage. circuit, leaks, fire, or other damage to the equipment. Incomplete drainage may cause wetting of the Be sure to use only accessories made by Daikin which building, furniture etc. are specifically designed for use with the equipment Do not let children play on and around the outdoor and have them installed by a professional.
-
Page 5: What To Do Before Operation
HAT TO DO BEFORE OPERATION PERATION RANGE This operation manual is for the following systems with standard Operation range control. Before initiating operation, contact your dealer for the operation that corresponds to your system type and mark. Use the system in the following temperature and humidity ranges for If your installation has a customized control system, ask your dealer safe and effective operation. -
Page 6: Program Dry Operation
For systems without cool/heat changeover remote control NOTE The heating capacity drops when the outside switch (See figure 3) temperature falls. If this happens, use another heating device together with the unit. (When using Press the operation mode selector button several times and together with appliances that produce open fire, ventilate the room constantly.) select the operation mode of your choice. -
Page 7: Adjusting The Air Flow Direction
6.3. Adjusting the air flow direction 6.5. Precautions for group control system or two remote controller control system Refer to the operation manual of the remote controller. This system provides two other control systems beside individual Movement of the air flow flap (See figure 7) control (one remote controller controls one indoor unit) system. -
Page 8: Maintenance
Symptom 4: The fan strength does not correspond to the setting. AINTENANCE The fan strength does no change even if the fan strength adjustment button in pressed. During heating operation, when the room temperature reaches 8.1. Maintenance after a long stop period (eg. -
Page 9: Troubleshooting
A hissing sound which is heard at the start or immediately after If the display , the unit number and the operation lamp TEST stopping operation or defrost operation. flash and the malfunction code appears; (See figure 6) This is the noise of refrigerant caused by flow stop or flow Inspection display change. -
Page 10: After-Sales Service And Warranty
11. A FTER SALES SERVICE AND WARRANTY NOTE Table 1 indicates main components. Refer to your maintenance and inspection contract for Warranty period more details. This product includes a warranty card that was filled out by the Table 1 indicates recommended intervals dealer at the time of installation. - Page 11 NOTES NOTES...
- Page 12 Zandvoordestraat 300, B-8400 Oostende, Belgium 4PWEN16234-1C...
