Daikin RE18MV2S Service Manual page 7

Si011193
Step
6 Remove the nut and
remove the outdoor fan.
7 Unfasten the 2 hooks.
Release the fan motor
lead wire.
Remove the 4 screws
8
and remove the fan
motor.
Removal Procedure
Procedure
D-cut
Outdoor
fan
Hook
Fan motor
Removal of Outdoor Fan / Fan Motor
Points
When reassembling, fit the
lower hooks into the bottom
frame.
(R15385)
Nut size: M6
Align the
(R15160)
outdoor fan with the D-cut
section of the motor shaft
when reassembling.
(R15161)
M4 × 16
(R15162)
10 mm
(R12236)
mark of the
5
