Removal of Electrical Components
Step
3. Remove the electrical
component.
Open the fuse cover
1
and remove the fuse.
2
Pull out the remaining
terminal [A2] from the
compressor capacitor
(C11R).
Remove the 2 screws
3
of the capacitor fixing
band.
Remove the
4
compressor capacitor.
10
Procedure
Fuse
Capacitor fixing band
Fuse cover
(R15176)
Compressor capacitor
(C11R)
to magnetic contactor K1M(3): red
B2
B1
(R15177)
(R15178)
(R15179)
Si011193
Points
A2
A1
(R15400)
Removal Procedure
