3192 Integrated Central Office Terminal (ICOT)
The alarm label as shown on the above illustation is placed on the ICOT for deployment with the Total
Access 1124. If the ICOT module is not being deployed with the Total Access 1124, remove this label from
the front panel.
61179512L2-10A
®
Document Addendum for 61179512L2-5A
H
D
S
L
R
S
2
3
2
TA1000 ICOT
1179512L2
LP1
LP2
DSX
LED is red and Craft port
ALM
is inoperative when
deployed with TA1124
LBK
NOTE
Section 61179512L2-10A
Issue 1, February 2004
CLEI Code: VACJCXBC_ _
Alarm Label
