New Classic Furniture B1564-400 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown.
PARTS LIST
No
Headboard
A
Footboard
B
Headboard Leg(L&R)
C
D Bed Roll-Out Slats
E Bed Slats Support
F Side Rail Left
G Side Rail Right
Center Slats
H
Side Rail Leg
I
Attach Head Board Leg ( C ) to Head Board ( A ) as shown using
STEP 1.1 :
Spring Washer (3), Flat washer (4)and securing with ALLEN KEY ( 5 ) .
STEP 1.2 :
Fix the other holes with Csk Screw (7) as shown.
A
RIGHT
NOTE : MUST TIGHTEN SCREWS PERIODCALLY WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
ASSEMBLY INSTRUCTIONS
PISCES
B1564-400 4/6 F PANEL BED-HB/FB/RAILS
ITEM Qty
1 pc
1 pc
2 pcs
2 sets
4 pcs
2 pcs
2 pcs
2 pcs
2 pcs
C
LEFT
BACK VIEW
STEP 1.1 :
HARDWARE LIST
No
JCBC M6 x 30mm
1
JCBC M6 x 50mm
2
Flat Washer 1/4"ID x
3
m4x65mm Blk
4
(FOR HB LEG)
m5x65mm Blk
5
(FOR SIDE RAIL)
Flat Head Chipboard
6
Screw m4x32mm Rbw
C
4
4x
ITEM Qty
12 pcs
4 pcs
12 pcs
19mmOD Blk
ALLEN KEY
1 pc
ALLEN KEY
1 pc
32 pcs
JCBC BOLT( 1 ) with
5
1
3 C
STEP 1.2 :
7
8x
1 OF 2
