Using the Software (cont'd)
The configuration software consists of the following areas:
1
2
6
Screenshot of TH1XD software interface
1. Celsius or Fahrenheit preference selection
2. Recording mode selection
• Stop_Recording: Logger will stop when memory is full
• Continuous_FIFO (first-in, first-out): Logger will replace first recorded data points with last
recorded data points
3. LCD Time Display
• Current: Logger LCD will display current time as configured in the software
• Duration: Logger LCD will display total running time from activation
14
3
4
5
7
8
9
10
11
12
13
