GO USB Loggers
User Manual
Cargo Monitoring Solutions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO USB Logger and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson GO USB Logger

Summary of Contents for Emerson GO USB Logger

  • Page 1 GO USB Loggers User Manual Cargo Monitoring Solutions...

  • Page 2: Table Of Contents

    Table of Contents Page Introduction Understanding the Device Display Information Battery Installation Operating Instructions GO USB Probe (TP1XD Model) Custom Instructions File Names and Extensions Understanding the PDF Data File 9-12 Configuration Software Using the Software 13-15 Troubleshooting and FAQ's 16-17 Technical Support...

  • Page 3: Introduction

    Introduction The family of GO USB Loggers are configurable temperature and humidity devices for your cold chain needs. An accompanying configuration software allows users to customize the logger to meet specific customer requirements. Data gathered and stored is easily accessible via a secure PDF file and available to share with key stakeholders.
  • Page 4 Understanding the Device GO USB Temperature (T1XD) USB connector cover LED light (Green = On, Red = Alert) Hang strap connector (side) LCD Display Start/Stop Operating Instructions (back side) (Navigation buttons) Battery compartment (back side) Probe jack Serial number (only for TP1XD) (bottom side) GO USB Probe (TP1XD) USB connector cover...

  • Page 5: Display Information

    Display Information The following icons are available and can be navigated by clicking the Start or Stop buttons. Temperature, Humidity (TH1XD) and Probe (TP1XD). Hourglass: When logger is in “start delay mode” or synchronizing with PC Max: Maximum ambient temperature and humidity (TH1XD), ambient temperature (T1XD), or ambient temperature and probe temperature (TP1XD) during the recording period.

  • Page 6: Battery Installation

    Battery Installation The GO USB Loggers come with pre-installed, non-rechargeable ER14250 ½ AA batteries. Ensure battery compartment is securely in place prior to use. Note: Once battery is depleted, it cannot be recharged and should be properly discarded according to local recycling guidelines. It is recommended that replacement batteries be the same make and model.
  • Page 7 Operating Instructions (cont’d) To cycle through the LCD information, click (short press) either the Start or Stop button. Navigation arrows indicates direction of information. You may wish to create “Marked events” on your PDF and CSV report to indicate an event or occurrence.

  • Page 8: Go Usb Probe (Tp1Xd Model) Custom Instructions

    GO USB Probe (TP1XD Model) Custom Instructions The TP1XD logger has been shipped with a pre-calibrated probe. Prior to using the probe, ensure that the probe serial number matches the serial number of the logger. The serial number is found on the flag sticker of the probe.

  • Page 9: File Names And Extensions

    File Names and Extensions The USB Loggers generate two (2) file types after connecting to the PC. • A secure PDF file that can be transferred to the PC and shared at any time. • A CSV file which can be transferred to the PC and shared at any time. For data integrity and security reasons, it is recommended to only share PDF files.
  • Page 10 Understanding the PDF Data File (cont’d) Every PDF report comes with a historical record in a graph and table form. If alert thresholds have been configured, they are displayed and color coded. A legend can be found below the graph as a reference. TP1XD graph example.
  • Page 11 Understanding the PDF Data File (cont’d) The final page of the PDF report is the Audit Trail. This page shows all interactions with the logger such as: • Original configuration date • Activation time • Deactivation time • File generation times •...
  • Page 12 Understanding the PDF Data File (cont’d) A CSV file is generated along with the PDF report. This file is generated for your convenience and can be used to create additional graphs or import data to a repository of choice. TH1XD CSV file example. Due to their editable nature, CSV files are not recommended to be used as a primary source of information when sharing amongst organization or parties within your organization.

  • Page 13: Configuration Software

    • Sound alarm: Disabled • Memory mode: Stop when full Download GO USB To install the software, visit Emerson.com/GOUSBLogger or use Logger Software the available QR code. Once downloaded, simply extract the .zip file to a desired location and run the executable file .

  • Page 14: Using The Software

    Using the Software (cont’d) The configuration software consists of the following areas: Screenshot of TH1XD software interface 1. Celsius or Fahrenheit preference selection 2. Recording mode selection • Stop_Recording: Logger will stop when memory is full • Continuous_FIFO (first-in, first-out): Logger will replace first recorded data points with last recorded data points 3.
  • Page 15 Using the Software (cont’d) 4. Interval settings: Change recording interval and start delay 5. Alert Settings: Change alert parameters • Enable Alerts: Enables alerts on Logger • Sound Alert: Enable buzzer on device 6. Alert Type: Change alert type • Consecutive alert mode •...

  • Page 16: Troubleshooting And Faq's

    Troubleshooting and FAQ’s When connecting the Logger to my PC, it generates a file name called “INTERIM.” What is wrong? The logger has not been manually stopped and is continuously recording temperature data (even during connection to PC.). You may transfer the file to your PC at any time. You can manually rename the file (Serial number can be found inside the PDF report).
  • Page 17 Troubleshooting and FAQ’s (cont’d) My logger has red markings on both the Graph and Running data tables. What does this mean? Someone has created marked events. Refer to the operating instructions of this manual for more information. After being connected to my PC, the temperature and humidity reading of the logger seem higher than usual.

  • Page 18: Technical Support

    Technical Support is available 24 hours a day, 7 days a week. We’re with you every step of the way. Toll Free: +1-877-998-7299 Emerson.com/Cargo CargoSupport@Emerson.com Live Chat TH1XD.UM.Rev1.0721 Emerson is a trademark of Emerson Electric Co. or one of its affiliated companies. ©2021 Emerson Electric Co. All rights reserved.
