TAVRIDA ELECTRIC VCB15 Product Manual page 32

Electrostatic discharge
Radiated EM field Immunity
Fast transient burst Immunity
Surge Immunity
Conducted disturbance induced by Radio frequency fields
Power Frequency Magnetic Field
Pulse Magnetic Field
100 kHz Damped Oscillatory Magnetic Field
1 MHz damped oscillatory magnetic field
AC Voltage Dips and Interruptions
Power Frequency Disturbance Voltage
100 kHz and 1 MHz Damped Oscillatory Wave Immunity
Ripple on DC Power Supply
DC Voltage Dips and Interruptions
1) Cable from electronic relay to connector block should be shielded and the case grounded near the connector. The total length of unshielded
wires from connector block to CM WAGO connector should not exceed 200 mm. Electromagnetic compatibility requirements are not
applicable for the CM USB port as this port is used only for CM programming during production and not used under service conditions.
2) Test influence is not applicable for CM "Close" and "Trip" dry contacts.
32
Parameter
Electromagnetic Compatibility (EMC) Requirements
Table 14 - CM EMC Parameters
Applicable standard
1)
IEC 60255-26
IEC 61000-4-2
IEC 60255-26
IEC 61000-4-3
IEC 60255-26
IEC62271-1
IEC 61000-4-4
IEC 60255-26
IEC 61000-4-5
IEC 60255-26
IEC 61000-4-6
IEC 60255-26
IEC 61000-4-8
IEC 61000-4-9
IEC 61000-4-10
IEC 61000-4-10
IEC 60255-26
IEC 61000-4-11
IEC 60255-26
IEC 61000-4-16
IEC 60255-26
IEC 62271-1
IEC 61000-4-18
IEC 60255-26 I
IEC 61000-4-27
IEC 60255-26
IEC 62271-100
IEC 61000-4-29
Rated Value
8 kV contact
15 kV air
80 MHz – 3 GHz
Sweep & spot
AM 1 kHz 80% 10 V/m
4 kV common mode
4 kV common mode
2 kV differential mode
150 kHz – 80 MHz
AM 1 kHz 80% 10 V
100 A/m continuously
1000 A/m 1 sec
1000 A/m
100 A/m
100 A/m
ΔU 30% 1 period
ΔU 60% 50 periods
ΔU 100% 5 periods
ΔU 100% 50 periods
300 V common mode
150 V differential mode 2)
2.5 kV common mode
1 kV differential mode
10% of Supply voltage,
100 Hz
ΔU 30% 2 sec
ΔU 60% 2 sec
ΔU 100% 0,3 sec
±20 % 10 sec
