3.2.2 CM Coding

Parameter
Parameter
description
Par1 Language
Rated supply voltage
Par2 and CM hardware
Par3 Firmware functionality
ISM driver firmware
Par4 used in CM
Protection setting
Factory configurable
Par5
1) This parameter describes the ISM type(s) that the CM can control. To optimize the operation of each ISM, corresponding settings are used
in the CM firmware. Usage of the CM with the incorrect type of the ISM can lead to a violation of declared VCB parameters.
Each CM has the following labels:
Figure 3
Serial number label
Figure 5
Warning label
16
Control module
Control module series
CM type
version
and
1)
Relay 1 - Switching module position functionality;
Relay 3 - Malfunction or Loss of auxiliary supply functionality;
settings
CM_16_1(Par1_Par2_Par3_Par4_Par5)
Table 6 - CM Parameters Description
Applicable options
English
Spanish
Portuguese
24-60V DC, version 2
110-220 V AC/DC, version 2
Basic circuit breaker functionality
ISM15_LD_8 and Without protection
ISM15_MD_1 and Without protection
ISM15_HD_1 and Without protection
ISM25_Shell_2 and Without protection
Relay 2 - Ready functionality;
Trip by dry contacts close command
Close by dry contacts close command
Figure 4
Label with applicable ISM designation
Figure 6
Firmware version label
Code
EN
ES
PT
60.2
220.2
1
15LD8-000
15MD1-000
15HD1-000
25Shell2-000
A.A
