The nameplate contains information about the VCB type, the VCB technical parameters and the serial number. The
placement of the electrical data label is shown below.
ISM electrical data label
a) VCB15_LD8_16D labeling
ISM electrical data label
c) VCB15_HD1_16D labeling
14
ISM electrical data label
ISM electrical data label
Figure 2
Electrical data label placement
b) VCB15_MD1_16D labeling
d) VCB25_Shell2_16D labeling
