Bell'O WAVS322 Assembly Instructions Manual

Wood audio video cabinet
Hide thumbs

Advertisement

Quick Links

Download this manual
WAVS322
WOOD AUDIO VIDEO CABINET
ARMOIRE AUDIO-VIDÉO EN BOIS
MESA DE MADERA PARA AUDIO Y VIDEO
ASSEMBLY INSTRUCTIONS
INSTRUCTIONS D'ASSEMBLAGE
INSTRUCCIONES DE ENSAMBLAJE
A SMALL AMOUNT OF PANEL FLEX IS COMMON IN WOOD PRODUCTS.
UN PETIT DEGRÉ DE FLÉCHISSEMENT DES PANNEAUX EST COURANT DANS LES PRODUITS EN BOIS.
ES NORMAL QUE LOS PRODUCTOS DE MADERA SE DOBLEN UN POCO.
Patent pending / Brevet en instance / Patent pendiente
Made in China / Fabriqué en Chine / Hecho en China
Italian designed / De design italien / De diseño italiano
ACPS-1_070110v1T
Do not discard these instructions / Ne pas jeter ces instructions / Conserve estas instrucciones

Advertisement

loading
Need help?

Need help?

Do you have a question about the WAVS322 and is the answer not in the manual?

Questions and answers

Related Manuals for Bell'O WAVS322

Summary of Contents for Bell'O WAVS322

  • Page 1 WAVS322 WOOD AUDIO VIDEO CABINET ARMOIRE AUDIO-VIDÉO EN BOIS MESA DE MADERA PARA AUDIO Y VIDEO ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE INSTRUCCIONES DE ENSAMBLAJE A SMALL AMOUNT OF PANEL FLEX IS COMMON IN WOOD PRODUCTS. UN PETIT DEGRÉ DE FLÉCHISSEMENT DES PANNEAUX EST COURANT DANS LES PRODUITS EN BOIS.
  • Page 2 ! NE PAS GRIMPER NI MARCHER SUR LE MEUBLE. ! NE PAS TAPER NI S’APPUYER SUR LES PLATEAUX. Bell'O International Corps décline toute responsabilité en cas d'assemblage non conforme aux instructions ou pour l'assemblage, l'utilisation ou la manutention incorrects de ce meuble.
  • Page 3 PARTS LIST / NOMENCLATURE DES PIÈCES / LISTA DE PIEZAS Quantity Quantity Part / Pièce / Pieza Part / Pièce / Pieza Quantité Quantité Cantidad Cantidad ACPS6 ACPS1 ACPS7 ACPS2 ACPS8 ACPS3 ACPS9 ACPS4 ACPS10 ACPS5 ACPS11...
  • Page 4 ASSEMBLY INSTRUCTIONS INSTRUCTIONS D’ASSEMBLAGE INSTRUCCIONES DE ENSAMBLAJE NOTE: 2 PEOPLE ARE RECOMMENDED TO ASSEMBLE THIS FURNITURE. TO AVOID DAMAGE DURING ASSEMBLY, IT SHOULD BE ASSEMBLED ON A SOFT SURFACE. REMARQUE : IL EST CONSEILLÉ D’ÊTRE À DEUX POUR ASSEMBLER CE MEUBLE. POUR ÉVITER LES DOMMAGES, EFFECTUER L'ASSEMBLAGE SUR UNE SURFACE DOUCE.
  • Page 5 ACPS10 Fig. 2 ACPS3 ACPS3 ACPS10 ACPS1 5. INSERT four Wood Dowels (ACPS10) into the holes in the top and bottom edges of EACH Center Divider Panel (ACPS3). 6. ATTACH the Center Divider Panels (ACPS3) to the Cabinet Back Panel (ACPS1) as shown above. 5.
  • Page 6 Fig. 3 ACPS4 ACPS10 ACPS2 7. INSERT a Wood Dowel (ACPS10) into the center front edge of the Bottom Panel (ACPS2). 8. Carefully LOWER the Front Door Frame (ACPS4) down on to the preassembled cabinet as shown. Make sure all Wood Dowels (ACPS10) are inserted properly into the holes in the back of the Front Door Frame.
  • Page 7 Fig. 4 ACPS5 ACPS10 ACPS6 Fig. 4B ACPS10 ACPS2 10. INSERT two Wood Dowels (ACPS10) into the bottom edge of the Right Rear Corner Panel (ACPS5) and the Left Rear Corner Panel (ACPS6). NOTE (!) the locations of the CMS ®...
  • Page 8 Fig. 5 ACPS7 ACPS10 ACPS5 ACPS4 ACPS10 ACPS1 ACPS6 12. INSERT two Wood Dowels (ACPS10) into the top edge of EACH Rear Corner Panel (ACPS5 & ACPS6). 13. INSERT one Wood Dowel (ACPS10) into the center top edge of the Back Panel (ACPS1), and INSERT one more Wood Dowel into the center top edge of the Front Door Frame (ACPS4).
  • Page 9 Fig. 6 ACPS11 16. INSERT all Shelf Supports (ACPS11) into the predrilled holes in the vertical panels of the cabinet interior. NOTE that EACH of the two side closed compartments get FIVE Shelf Supports. Also make sure that all Shelf Supports are installed at the same height so the Shelves will be level once in place.
  • Page 10 Fig. 7 ACPS9 ACPS8 ACPS9 17. Carefully INSERT the Shelves into place as shown. Make sure all the shelves are securely placed onto all Shelf Supports (ACPS11) and level before attempting to place any components or items on the Shelves. 17.

  • Page 11: Warranty

    This warranty gives you specific legal rights. You may also have other rights, which vary from state to state. BELL'O INTERNATIONAL CORPORATION, 711 Ginesi Drive, Morganville, NJ 07751-1235 Phone: (732) 972-1333 Fax: (732) 536-6482 Web: www.bello.com E-mail: sales@bello.com...
  • Page 12 Garantía limitada de un (1) año Se le garantiza al comprador original este producto Bell'O International Corporation, con excepción del vidrio, durante un período de un (1) año a partir de la fecha de la compra. Se le garantiza al comprador original el vidrio durante un período de treinta (30) días a partir de la fecha de la compra. Esta garantía se limita expresamente a los productos nuevos comprados en cajas cerradas en fábrica.
