MODELS AVAILABLE:
AR-2010 (CLEAR ANODIZED)
AR-2010-BLK (BLACK ANODIZED)
AR-2010 AluRack Crossbar Module, 53" Kit
Page 2
Packaging Contents
Page 2–3
Crossbar Installation (Retrofit on Existing Rack)
Page 3
Crossbar Configurations–Maximum Spacing
Page 4-7
Full Rack Assembly
PRIME DESIGN, A SAFE FLEET BRAND
Address: 580 Opperman Drive, Eagan, MN 55123 ▪ Toll Free: 1.8.PRIME.RACK
Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Safe Fleet PRIME DESIGN AR-2010
Summary of Contents for Safe Fleet PRIME DESIGN AR-2010
- Page 1 Crossbar Installation (Retrofit on Existing Rack) Page 3 Crossbar Configurations–Maximum Spacing Page 4-7 Full Rack Assembly PRIME DESIGN, A SAFE FLEET BRAND Address: 580 Opperman Drive, Eagan, MN 55123 ▪ Toll Free: 1.8.PRIME.RACK Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net...
- Page 2 CONTENTS OVERVIEW AluRack Heavy Duty Crossbar ......(Qty 1) With hardware, 53.00” Clear or Black (BLK), Anodized Roller Hardware ............ (Qty 1) M8 Strip Nut (2X) M8 Lock Washer (2X) M8 Cap Head Bolt (2X) CROSSBAR INSTALLATION (RETROFIT ON EXISTING RACK) The AluRack shown below is for illustrative purposes only, and shows a combination of Standard and Heavy Duty Crossbars.
- Page 3 CROSSBAR ADDITION (OR REPLACEMENT) NOTE: Heavy Duty Crossbars are used for mounting your rack to the FBM, and must be in the original mounting position. The rest of the confguration may be adjusted to customer needs. The AluRack shown below is for illustrative purposes only, and shows the orginal Crossbars with a new Crossbar in addition.
- Page 4 STRIP NUT INSTALLATION (FULL RACK ASSEMBLY) NOTE: The AluRack shown below is for illustrative purposes only, and shows a combination of Standard and Heavy Duty Crossbars. Spacing and sizing will vary according to customer needs (see Crossbar Configurations Chart on previous page). Maximum bolt spacing between Roller and Crossbars is 24.00”.
- Page 5 LEFT SIDE RAILS AND CROSSBARS Install the Crossbars according to your configuration in the Strip Nuts as shown and torque to 90 in-lbs. RIGHT SIDE RAILS AND CROSSBARS Install the Crossbars according to your configuration in the Strip Nuts as shown and torque to 90 in-lbs.
- Page 6 ROLLER ASSEMBLY Insert the Roller Tube Pin and Roller Tube Spring into the Roller ends. ROLLER INSTALLATION Insert the Roller Tube Pin on each side of the Roller Tube into the Brackets as shown. Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability (the “Prime Design Limited Warranty”).
- Page 7 FINAL INSTRUCTIONS (FULL RACK ASSEMBLY) Do not mount the AluRack to an FBM system at this time. Refer to the respective FBM Assembly Manual(s) included with your chosen rack configuration features. WARNING: Failure to position the AluRack as shown in your FBM Assembly Manual may result in damage to the ladder rack.
- Page 8 USAM-AR2010-US01 Rev-A 0419...
