- Page 1 AUTOPLUS 4-2/5-2 Automotive Exhaust Gas Analyzer INSTRUCTION MANUAL ENGLISH ZERO CAL TIME 13 01:17:35PM 18/04/12 AUTO + GAS ANALYSER 1-800-547-5740 • Fax: (503) 643-6322 www.ueitest.com • Email: info@ueitest.com...
-
Page 2: Table Of Contents
8. ZERO CHECKS AND RE-CALIBRATION ..............31 - 32 8.1 Zero Setting ......................31 9. PRODUCT SPECIFICATION FOR HANDHELD AUTOPLUS 4-2 AND AUTOPLUS 5-2 ..............32 - 33 APPENDICES ........................33 - 35 A. MAIN DISPLAY PARAMETERS ................33 B. LAMBDA CALCULATION ..................34 B-1. -
Page 3: Autoplus 4-2/5-2 Layout And Features
1. AUTOPLUS 4-2/5-2 LAYOUT AND FEATURES 1.1 FEATURES AND KEYPAD INFRA-RED SIGNAL TO PRINTER GAS CONNECTION TO INSTRUMENT BATTERY CHARGER EXTERNAL PARTICLE OR 12V ADAPTER FILTER IN-LINE WATERTRAP (KEEP CLEAR OF WATER AT ALL TIMES) WATER LEVEL LIMIT AUTO +... -
Page 4: Layout (Rear)
1. AUTOPLUS 4-2/5-2 LAYOUT AND FEATURES (CONT.) 1.2 LAYOUT (REAR) BUILD STATUS LABEL CHARGER SOCKET AUTOplus 3-2 AUTOplus 4-2 AUTOplus 5-2 EXHAUST PORT KANE INTERNATIONAL LTD Swallowfields Welwyn Garden City Herts. AL7 1JG Tele: +44 (0) 1707 375550 Fax: +44 (0) 1707 393277 Serial No. -
Page 5: Standard Probe Configuration
Steel Shaft Note: A variety of probes are available, including high temperature probes necessary for on-road / rolling road vehicle testing when the temperature of the emission gases increase. Please request further details from your distributor or contact UEi directly. -
Page 6: Safety Warning
2. SAFETY WARNING This analyzer extracts combustion gases that may be toxic in relatively low concentrations. These gases are exhausted from the back of the analyzer. This analyzer must only be used in well-ventilated locations. It must only be used by trained and competent persons after due consideration of all the potential hazards. Protection Against Electric Shock (in accordance with EN 61010-1 : 2010) This analyzer is designated as Class III equipment and should only be connected to SELV circuits. -
Page 7: Normal Start Up Sequence
4. NORMAL START UP SEQUENCE 4.1 EVERY TIME YOU USE THE ANALYZER • BEFORE SWITCH-ON CHECK THAT: • the particle filter is dry and not dirty or damaged • the water trap and probe line are empty of water • all hose connections, etc, are properly made •... - Page 8 (If the charger is connected and is pressed the display will show) Press again and the display header screen will be shown. NOTE: When the “CHARGING BATTERY” screen is displayed fast charging mode is operating.) And then the initializing screen is shown: FRESH PURGE TIME...
- Page 9 TIP: Take care to purge the analyzer in really fresh air. Often the air in a garage or workshop is contaminated with HC up to about 2 meters from the floor with the emissions from past spills of oil, lubricants etc., that may have soaked into the floor. Once the initialization is completed the analyzer will zero the CO, HC, CO2 and NO sensors if fitted and set oxygen to 20.9%.
-
Page 10: The Keypad
4.3 THE KEYPAD The keypad has 8 keys: - ON/OFF - UP - DOWN - ENTER - PUMP toggle - PRINT ..and SEND - STORE - MENU • ON/OFF: Turns the analyzer ON or OFF. If you press OFF by mistake simply press ENTER to cancel. •... -
Page 11: Menu
• STORE: Press to log readings from the screen into memory. The log number of the readings is displayed for a few seconds in the top left hand corner of the screen. LOG 005 0000 0000 20.9 ---- 15:13:27 03/22/15 - You can LOG up to 500 sets of readings. - Page 12 Pressing the MENU key causes the following screen to be displayed MENU SETUP UNITS SCREEN REPORTS SERVICE MANUAL ZERO 12.52.30 pm 03/22/15 to scroll the cursor through the selection and the press to choose, to exit this screen press MENU again. SETUP MENU LANGUAGE...
- Page 13 LANGUAGE: to change. Use to accept. MENU LANGUAGE = English = French = German = Dutch 12.52.30 pm 03/22/15 PUMP: Pump speed can be set from 1 (slowest ) to 4 (fastest). to change. Use to accept. MENU PUMP 12.52.30 pm 03/22/15...
- Page 14 PRINTER: Select from the following communication methods to change. Use to accept. MENU PRINTER = KANE IRP-2 = KANE IRP = USB-SERIAL = BLUETOOTH 12.52.30 pm 03/22/15 SET TIME: to change. Use to accept and move the cursor. MENU SET TIME 30 am 12.52.30 pm 03/22/15...
- Page 15 SET DATE: to change. Use to accept and move the cursor. Date format can also be changed before the date by using the same method. MENU SET DATE 12.52.30 pm 03/22/15 NOTE: If ‘FUNCTION LOCKED’ appears, delete all reports (see p20-22). Date format can also be changed before the date by using the same method.
- Page 16 UNITS: to change. Use to accept. MENU FUEL VEHICLE BACK 12.52.30 pm 03/22/15 FUEL: NOTE: when diesel is selected HC and Lambda are not displayed. MENU FUEL = gasoline/petrol = LPG = CNG = DIESEL 12.52.30 pm 03/22/15...
- Page 17 VEHICLE: allows a vehicle registration number to be entered. to change. Use to accept. MENU VEHICLE: VE05DPZ 12.52.30 pm 03/22/15 EFF: Set Lambda or AFR to change. Use to accept. MENU EFF: = LAMBDA = AFR 12.52.30 pm 03/22/15...
- Page 18 PEF: (Propane Equivalency Factor) displays value only. MENU PEF: 0.545 12.52.30 pm 03/22/15 Example: 1000ppm of HC (hexane) / PEF = 1835ppm (propane) MEF: (Methane Equivalency Factor) displays value only. MENU MEF: 0.0545 12.52.30 pm 03/22/15 Example: 1000ppm of HC (hexane) / MEF = 18,349ppm (methane)
- Page 19 SCREEN MENU CONTRAST BACKLIGHT LINES BACK 12.52.30 pm 03/22/15 to change. Use to accept. CONTRAST: set contrast from 1 to 15 MENU CONTRAST 12.52.30 pm 03/22/15...
- Page 20 BACKLIGHT: adjust switch off time from 30 to 300 secs. MENU B’LIGHT 12.52.30 pm 03/22/15 LINES: Allows the main display to be configured by the user. MENU LINE 1 = CO2% ----% LINE 2 LINE 3 LINE 4 LINE 5 LINE 6 EXIT 12.52.30 pm...
- Page 21 REPORTS MENU VIEW REPORTS DELETE ALL REPORTS AUTO LOG TIME START AUTO LOG HEADER 1 HEADER 2 BACK 12.52.30 pm 03/22/15 VIEW REPORTS MENU LOG 13 Date: 07/10/11 Time: 03:35 VEHICLE: VE05DPZ FUEL: DIESEL 14.4% 0.05% 1.1% ---- 150 ppm ---- 12.52.30 pm 03/22/15...
- Page 22 DELETE ALL REPORTS: MENU DELETE ALL? 12.52.30 pm 03/22/15 MENU CONFIRM DELETE? 12.52.30 pm 03/22/15...
- Page 23 AUTOLOG TIME: Can be set from 5 secs to 300 secs. MENU AUTOLOG TIME = 10 12.52.30 pm 03/22/15 NOTE: If the PUMP is switched off then AUTOLOG is inhibited START AUTOLOG TIP: Before starting AUTOLOG you might want to manually re-zero the analyzer so that you have 30 minutes of logging time before a re-zero is requested.
- Page 24 HEADER 1 & HEADER 2 allows inputting of company details to appear on two lines of the printout MENU HEADER 1: Company Name 12.52.30 pm 03/22/15 MENU HEADER 2: Phone number? 12.52.30 pm 03/22/15 to change. Use to accept.
- Page 25 SERVICE MENU CODE = 0000 CAL DATE = 369 12.52.30 pm 03/22/15 CODE entry is reserved for approved service agents. CAL DATE is the countdown for days remaining until annual calibration is due. MANUAL ZERO This allows the user to manually re-zero the analyzer REMOVE PROBE FROM EXHAUST PRESS ENTER TO ZERO 12.52.30 pm...
-
Page 26: Sampling The Exhaust Gas
4.5 SAMPLING THE EXHAUST GAS Once the zero calibration and test procedures have been completed and the fuel has been selected the probe can be inserted into the desired vehicle exhaust. Ensure the probe is inserted into the exhaust pipe so as to not allow air into the probe. The exhaust of a car can pulse, especially at low RPM, drawing air in causing bad readings, ensure the flexible probe is fully inserted and the clip attached to the exhaust pipe. -
Page 27: Regular Checks During Sampling
4.7 REGULAR CHECKS DURING SAMPLING Care must be taken at all times not to exceed the analyzers operating specifications, in particular ensure the following :- • DO NOT PLACE THE ANALYZER IN THE ENGINE BAY. • Do not expose the analyzer to temperatures outside its normal operating range. •... -
Page 28: Printing Information-Optional Extra Only
OFF 30 PRESS ENTER TO GO BACK 12.52.30 pm 03/22/15 If you have not finished but press by mistake, you can press to return to normal operation and not switch OFF. TIP: It’s a good idea to empty the water trap after testing so that the risk of water getting on to the particle filter or into the analyzer is minimized. -
Page 29: Standard Printout
5.2 STANDARD PRINTOUT The standard printout is shown below :- AUTOplus V1.00 SERIAL No. 030912287 Kane Auto Plus (44) - 1707 - 375550 DATE: 09/07/12 TIME: 08:25:33AM VEHICLE AB11 DEF FUEL GAS/PETROL %… 20.95 ---- Lambda ---- NOTE: The analyzer will stop logging once it has reached 500 readings and will return to the main display is pressed. -
Page 30: Changing The Particle Filter
Carefully remove the end cap from the in-line housing. Dispose of the condensate in a suitable drain. Clean the inside of the water trap using a soft cloth 6.2 CHANGING THE PARTICLE FILTER This is a very important part of the analyzer and should be changed regularly. It prevents dust and dirty particles entering the pump and sensors and hence causing damage. -
Page 31: Zero Checks And Re-Calibration
If you suspect the internal filter is blocked perform the following: • Remove the probe connection from the water trap. • Empty and clean the water trap with a dry cloth. • Fit a new external particle filter. • Run the analyzer in fresh air (pump ON) for at least one hour. If the problem does not clear contact a service agent Fault symptom Causes... -
Page 32: Product Specification For Handheld
WARNING : The sensors will only be reset if the probe is sampling fresh air for at least 60 seconds. Once the zero is complete the screen will return to the MAIN DISPLAY. 9. PRODUCT SPECIFICATION FOR HANDHELD AUTOPLUS 4-2 & AUTOPLUS 5-2 Parameter... -
Page 33: Appendices
Sensor response T Nominal 20 seconds AUTOPLUS 3-2, 4-2, 5-2. Warm up Less than 2 minutes Pre-programmed Fuels Petrol/Gasoline, LPG, Diesel, and CNG. PC connection Via Mini USB or Bluetooth Data-Logging 500 Tests Dimensions Weight Handset 220mm x 55mm x 120mm Probe Insertion depth 350mm x Diameter 15mm Clip handle to secure to exhaust, 4m long hose... -
Page 34: Lambda Calculation
• CO : Carbon monoxide measured in the exhaust gas indicated in percentage %. With the pump off the analyzer will display - - - -. If there is a fault with the CO reading then FLT will be displayed. •... -
Page 35: B-1. Oxygen Balance Formula
of Lambda when certain components of the exhaust are measured. B.1 OXYGEN BALANCE FORMULA For Lambda calculation, based upon measurements of CO, CO2, HC and O2, the following formula is stan- dardized: Displayed on the analyzer as LAMBDA (O) = CO2 + (CO/2) + O2 + [HCV/4 × {3.5 / (3.5 + CO/CO2)} – OCV/2] × (CO2 + CO) (1 + HCV/4 - OCV/2) ×... -
Page 36: Limited Warranty
Any implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose, are limited to the express warranty. UEi shall not be liable for loss of use of the instrument or other incidental or consequential damages, expenses, or economic loss, or for any claim or claims for such damage, expenses or economic loss.
