- Page 1 ™ PCIO USER’S MANUAL Part Number 4035 Sealevel Systems, Inc Phone: (864) 843-4343 155 Technology Place Fax: (864) 843-3067 P.O. Box 830 www.sealevel.com Liberty, SC 29657...
-
Page 2: Table Of Contents
Contents ................ 1 NTRODUCTION ................... 1 VERVIEW ’ ................1 NCLUDED ............. 1 ACTORY EFAULT ETTINGS ................2 ETUP ............2 ERIAL DDRESS ELECTION ..........3 ARALLEL DDRESS ELECTION ..............3 NABLE ISABLE IRQ S ................... 4 ELECTION ................4 NTERRUPT ODES E1 .................. - Page 3 Figure 3 - Address Selection Table ..............3 Figure 4 - DIP-Switch SW1 Illustration............3 Figure 5 - Header E1 and E3, Interface Selection Options......5 Figure 6 - Interface Option Examples..............6 Figure 7 - Asynchronous Communications Bit Diagram.......18 © 1998a Sealevel Systems, Incorporated. All rights reserved.
-
Page 5: Introduction
RS-232 Parallel Port Bi-directional To install the PCIO using factory default settings, refer to Installation on page 7. For your reference, record installed PCIO settings below: Port Base Address Electrical Specification Serial Port Parallel Port Sealevel Systems PCIO Page 1... -
Page 6: Card Setup
Figure 2 - DIP-Switch SW2 Illustration Note: Setting the switch ‘On’ or ‘Closed’ corresponds to a ‘0’ in the address, while leaving it ‘Off’ or ‘Open’ corresponds to a ‘1’. Refer to Appendix A for common address contentions. Sealevel Systems PCIO Page 2... -
Page 7: Parallel Port Address Selection
DIP-switch. The port is enabled with the switch ‘On’ or ‘Closed’ and disabled when ‘Off’ or ‘Open’. If any port is disabled, be sure to disable the interrupt request for that port by removing the IRQ jumper. Sealevel Systems PCIO Page 3... -
Page 8: Irq Selection
The multi interrupt mode allows you to share the IRQ signal(s) with other cards that support multiple interrupts. The ‘M’ and ‘N’ selections for the serial port are under ‘SP’ and labeled ‘PP’ for the parallel Port. Sealevel Systems PCIO Page 4... -
Page 9: Headers E1
"A" Enables DSR; "B" sets DSR Active "A" Enables CTS; Remove to set Active "A" Selects RS-232 Receive Data; "B" Selects RS-422 Receive Data A | B Figure 5 - Header E1 and E3, Interface Selection Options Sealevel Systems PCIO Page 5... -
Page 10: Figure 6 - Interface Option Examples
Card Setup RS-232 RS-422 RS-485 A | B A | B A | B A | B A | B A | B Figure 6 - Interface Option Examples Sealevel Systems PCIO Page 6... -
Page 11: Installation
Install the parallel port as a standard Windows parallel port. Other Operating Systems Refer to the appropriate section of the Serial Utilities Software. Install the parallel port as a standard parallel port by following your operating system’s instructions Sealevel Systems PCIO Page 7... -
Page 12: Technical Description
• Support for non-standard baud rates available. These baud rates (such as 31.25K or 76.8K baud) are supported by installing a different oscillator. Please consult Sealevel Systems Technical Support for more information Modem Control Signal Considerations Some software packages require the use of the modem handshake signals such as CTS or DCD. -
Page 13: Connector Pin Assignments
RTS to CTS and RI. Also, connect DCD to DTR and DSR. Terminating these pins, if not used, will help insure you get the best performance from your adapter. Sealevel Systems PCIO Page 9... -
Page 14: Parallel Port
Data Bit 4 Input/Output Data Bit 5 Input/Output Data Bit 6 Input/Output Data Bit 7 Input/Output -ACK Input Busy Input Input SLCT Input -Auto Feed Output -Error Input -INIT Output -SLCT IN Output Ground 18-25 Sealevel Systems PCIO Page 10... -
Page 15: Specifications
IPC 610-A Class-III standards are adhered to with a 0.1 visual A.Q.L. and 100% Functional Testing. • All Sealevel Systems Printed Circuit boards are built to U.L. 94V0 rating and are 100% electrically tested. These printed circuit boards are solder mask over bare copper or solder mask over tin nickel. -
Page 16: Appendixa - Troubleshooting
No two adapters can occupy the same I/O address. 3. Make sure the Sealevel Systems adapter is using a unique IRQ. While the Sealevel Systems adapter does allow the sharing of IRQ’s, many other adapters (i.e. SCSI adapters & on-board serial ports) do not. The IRQ is typically selected via an on-board header block. - Page 17 2E8-2EF is typically reserved for COM4: 7. Please refer to your included diskette for any post production manual updates and application specific information. 8. Always use the Sealevel Systems diagnostic software when Troubleshooting a problem. This will eliminate the software issue from the equation.
-
Page 18: Appendixb - How T O Get Assistance
3. Sealevel Systems maintains a forum on CompuServe which can be accessed by typing ‘GO Sealevel’ at the command prompt. 4. Technical support is available Monday to Friday from 8:00 a.m. -
Page 19: Appendixc - Electrical Interface
-12 volts (-3 to -10 volts) denotes a binary 1 (mark). The RS-232 and the EIA/TIA-574 specification defines two type of interface circuits, Data Terminal Equipment (DTE) and Data Circuit-Terminating Equipment (DCE). The Sealevel Systems adapter is a DTE interface. RS-422 The RS-422 specification defines the electrical characteristics of balanced voltage digital interface circuits. -
Page 20: Centronics And Bi-Directional Parallel Ports
Amphenol style interface common to the Centronics printers would not fit well on a PC bracket. The choice of a female connector was made to avoid confusion with the RS-232 port which was male. Sealevel Systems PCIO Page 16... - Page 21 “switch”. The bi-directional mode the 8 bit output port can be changed from output to input and vice versa by setting bit D5 in the base +3 address (see Card Setup section for software examples). Sealevel Systems PCIO Page 17...
-
Page 22: Appendixd - Asynchronous Communications
The data rate and communication parameters for asynchronous communications have to be the same at both the transmitting and receiving ends. The communication parameters are baud rate, parity, number of data bits per character, and stop bits (i.e. 9600,N,8,1). Sealevel Systems PCIO Page 18... -
Page 23: Appendixe - Compliance Notices
Always use cabling provided with this product if possible. If no cable is provided or if an alternate cable is required, use high quality shielded cabling to maintain compliance with FCC/EMC directives. Sealevel Systems PCIO Page 19... -
Page 24: Warranty
Should this product fail to be in good working order at any time during this period, Sealevel Systems will, at it's option, replace or repair it at no additional charge except as set forth in the following terms. This warranty does not apply to products damaged by misuse, modifications, accident or disaster.
