1
重点
项目
校对项
库
文件名
A
1.结构尺寸
2.材质标注
3.物料编码
B
4.颜色标注
5.客户型号
6.电压功率
C
7.变量规则
8.条码内容
码制
D
9.产品名称
10.认证标志
、警语字体
E
1.未注直线尺寸公差应符合GB/T1804-v；
F
2.说明书警语及认证标志应满足CE/UL标准，CE：警语部分大写字母高度不低于3mm，CE标志不低于5mm，WEEE标志不低于7mm；
UL：大写字母字高不小于1/12"(2.11mm)，小写字母字高不小于1/16"(1.6mm)，"IMPORTANT SAFEGUARDS"，"SAVE
THESE INSTRUCTIONS"等词，其字高不小于3/16"(4.8mm)，IMPORTANT SAFEGUARDS 必须在最前面。
3.产品应符合QMG-J53.021《产品说明书技术条件》的有关要求。
4.有ROHS指令要求的物料应符合美的企业标准QML-J11.006《产品中限制使用有害物质的技术标准》。
制 图
G
设 计
校 对
比 例
变更记录
H
1
2
OWNER'S MANUAL
Digital Tower Ceramic Heater
READ AND SAVE THESE INSTRUCTIONS
[一般70P以下为钉装，70P以上为胶装（特殊要求除外）]
审 核
李海棣
颜雅丽
颜雅丽
标准化
古广君
张益
古广君
审 定
1：1
2
3
Model: NTH15-22GR
Attention: Pictures in the IM are for reference only.
技术要求(版本号:B，2020-01）
产品
取暖器
品类
物 料 编 码
工厂型号/客户型号
客 户 名 称
材 质
颜 色
尺寸规格（单位:mm)
环 保 要 求
其他要求:
1: 印刷字体需清晰可见，
文字不能粘到一起
3
4
5
物料
名称
技术要求参数表
00000000000000（待更新）
NTH15-22GR
Midea
70g双胶纸
单色印刷 双面印刷
145*210mm
环保
广东美的生活电器制造有限公司
5
4
6
A
B
C
D
E
F
说明书
G
H
6
Advertisement
Table of Contents
Related Manuals for Midea NTH15-22GR
Summary of Contents for Midea NTH15-22GR
- Page 1 重点 项目 校对项 库 文件名 1.结构尺寸 2.材质标注 3.物料编码 OWNER’S MANUAL 4.颜色标注 Digital Tower Ceramic Heater Model: NTH15-22GR 5.客户型号 6.电压功率 7.变量规则 8.条码内容 码制 9.产品名称 10.认证标志 、警语字体 READ AND SAVE THESE INSTRUCTIONS Attention: Pictures in the IM are for reference only. 技术要求(版本号:B，2020-01）...
- Page 2 OWNER’S MANUAL Digital Tower Ceramic Heater Model: NTH15-22GR READ AND SAVE THESE INSTRUCTIONS Attention: Pictures in the IM are for reference only.
-
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances,basic precautions should always be followed to reduce the risk of fire,electric shock,and injury to persons,including the following: 1. Read all instructions before using heater. 2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surface. -
Page 4: Display Screen
12. To disconnect the heater, first turn controls to off, then remove plug from outlet. Never pull by the cord. 13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage the heater. 14. -
Page 5: Function Setting
Oscillation Function Display area Timer ON/OFF OPERATING INSTRUCTION Check before turning on the machine 1. Check if the power wire is under good condition. 2. The product adopts 120V AC power supply, before use, please confirm if the rated current of the power socket meets the local requirements with safe grounding device, otherwise, please replace it with the qualified socket. -
Page 6: Oscillation Function
Oscillation function The electric heater in operation mode, press the "Oscillation" key to open the oscillation function, pressing this button to turn off the oscillation function; when the electric heater stops heating function, the wind oscillating function also stop. Temperature sensor short circuit, open circuit protection function No matter in what mode, the temperature sensor appears short circuit or open circuit, digital screen displays "E1"... -
Page 7: Troubleshooting
HIGH OSC 1500 1500 NTH15-22GR TROUBLESHOOTING If the product does not operate or does not operate properly, first check according to the following list. If the reason the product does not operate or does not operate properly is not included in the following list, the product mayhave failed.
