维修手册
适用机型
（本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and
specific appearance and configuration are subject to the real product)
编制
审核
批准
Service Manual
Applicable Models
NTH15-18MR
Prepared by
Reviewed by
Approved by
维修手册
Service Manual, 2017 v1.0
机型编码
Model No.
92057014Z00041
陈洋
梁义忠
孙彬
1 / 11
Advertisement
Related Manuals for Midea NTH15-18MR
Summary of Contents for Midea NTH15-18MR
- Page 1 维修手册 Service Manual, 2017 v1.0 维修手册 Service Manual 适用机型 机型编码 Applicable Models Model No. NTH15-18MR 92057014Z00041 （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) 编制 陈洋 Prepared by 审核 梁义忠 Reviewed by 批准...
-
Page 2: Important Safety Notice
Midea Environment Appliance Technical Maintenance Manual Copyright @2016 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales Corporation of Midea Environment Appliance. 2 / 11... -
Page 3: Safety Warning Code
维修手册 Service Manual, 2017 v1.0 安全警示规范 Safety Warning Code WARNING Read these instructions. Keep these instructions. Follow all instructions. Do not use this appliance near water. This appliance is intended to be used in household and similar environments. Clean only with a damp cloth. Install in accordance with the manufacturer’s instructions. - Page 4 维修手册 Service Manual, 2017 v1.0 整机拆卸 Dismantling of appliance 拆后壳 Open the back shell 拆出图示的 6 颗螺丝后将后壳拆出 Remove the 6 screws shown to remove the back cover 风机组件、PTC 发热体、前网及出风口拆卸 Fan assembly, PTC heater, front net and outlet. 1 拆出图示 4 颗螺钉，将风机组件拆出，下面 为...
- Page 5 维修手册 Service Manual, 2017 v1.0 2.3 同步电机拆卸 Dismantle synchronous motor 拆出图示 3 颗螺钉，将同步电机以及连杆拆出 Pull out 3 screws and pull out the synchronous motor and connecting rod. 底座拆卸 Dismantle the base 拆出图示 3 颗螺钉，拆出底盖 Pull out 3 screws and remove the bottom cover. 2.5 拆电路板和功能板...
-
Page 6: Function And Operation
维修手册 Service Manual, 2017 v1.0 1.拆出图示 1 颗螺钉，拆出通用电路板； 2.拆出图示 3 颗螺钉，拆出控制电路板 1 disassemble 1 screws and disassemble the general circuit board. 2. disassemble 3 screws and remove the control circuit board. 整机的安装 Function and operation 电路板、功能板安装 Circuit board and function board installation 1.安装图示... - Page 7 维修手册 Service Manual, 2017 v1.0 安装底座 Mounting base 安装图示 3 颗螺钉，紧固底盖 Install 3 screws and tighten the bottom cover. 同步电机安装 Synchronous motor installation 紧固图示三颗螺钉，将同步电机固定在摇头 支架及底座上 Tighten three screws and fix the synchronous motor on the shaking head bracket and the base. 风机组件、PTC 发热体、前网及出风口安装...
- Page 8 维修手册 Service Manual, 2017 v1.0 1.紧固图示两颗螺钉， 将出风口安装到前壳上 2.将前网图示扣脚扣到前壳相对应的扣位处 紧固 3.紧固图示两个大垫圈头螺钉，紧固 PTC 与 出风格栅 4.将风机组件放到前壳上相应位置， 紧固图示 4 颗螺钉，固定风机组件 1. tighten the two screws and install the outlet on the front shell. 2. fasten the front buckle to the buckle position of the front shell. 3.
-
Page 9: Fault Code And Solutions
维修手册 Service Manual, 2017 v1.0 常见及解决方法 Fault code and solutions 故 障 代 代 码 可 故 障 内 容 显示 维修方法步骤 码 见 Display Steps for maintenance methods Fault Fault Code content code visible 数 码 管 双 8 持... - Page 10 维修手册 Service Manual, 2017 v1.0 附录 Appendix: 整机接线图 Electrical Schematic Diagram 暖风机维修常用工具、设备和材料 refrigerator maintenance tooling and equipment and material 工具 Tooling 名称 图片 主要用途 Name Photo Main Usage 十字螺丝刀 拆卸螺钉 Phillips screw assemble and screwdriver disassemble 平口螺丝刀/小铲刀 拆卸螺钉和铆钉 screw and slotted screwdriver/scraper rivet assemble and disassemble 10 / 11...
- Page 11 维修手册 Service Manual, 2017 v1.0 拆卸铰链、压缩机螺钉 hinge 套筒扳手 Socket spanner and compressor screw assemble 5/16″ and disassemble 尖嘴钳 辅助工具 Nipper pliers assistive tool 11 / 11...
