Indicator Terminology
SINT8 - 1 byte
UNIT8 - 1 byte
SINT16 - 2 byte
UNIT16 - 2 byte
SINT32 - 4 byte
UNIT32 - 4 byte
FLOAT - 4 byte
STRING - 1 byte/char
The Type and order of the Values selected must coincide with the configuration of the
PLC register setup. Consult with the site IT specialist.

6.4.6 Printer

The Printer menu is used when the indicator is interfaced with one of the printers
listed in the Brand submenu. This is necessary to ensure all the appropriate control
codes are added to the selected print format.
If either PRTR1 or PRTR2 selections are enabled then the port that is Binded may
occasionally send out a set of random characters to test for a connected printer. Be
sure to disable these settings if the indicator is not connected to one of the printer
brands listed.
Prtr 1
T419S Indicator Service Manual
DATA TYPE TABLE
Typical PLC Terminology
CHAR / SBYTE 8 Bits (Signed Value / -127 to 127)
BYTE / UBYTE 8 Bits (Unsigned Value / 0-255)
SHORT / SINT 16 Bits (Signed Value /-32767 to 32767)
WORD / UINT 16 Bits (Unsigned Value / 0 to 65535)
LONG / SDINT 32 Bits (Signed Value / -2,147,483,647 to 2,147,483,647)
DWORD / UDINT 32 Bits (Unsigned Value / 0 to 4,294,967,295)
REAL 32 Bits (Signed Decimal Value / 1.0E-37 to 1.0E37
STRING Length Parameter setting
Out This stands for outbound data configuration. This menu item
is exactly like the in menu item except it is for outbound data.
Follow the same process to set up the 32 memory registers.
You can choose to set up this printer or Prtr 2. The setup procedure is the
same.
Type Below is a table showing the choices
for the Type, a description and a range
of values for that data type.
Data TYPE Size
Value This stands for the network token value
to be assigned to the inbound data
memory register. Key in the value for
the network token you want from the
table above and press ENTER to
accept the displayed choice ...
Repeat the process for any other
inbound memory registers you want to
configure.
Scale Choose from connected scales.
