- Page 1 T104 Series Indicators Instruction Manual...
-
Page 3: Table Of Contents
T104 Series Indicators EN-1 Table of Content INTRODUCTION ............................3 1.1. Safety Precautions ...........................3 1.2. Intended Use ............................3 1.3. Overview of Parts and Controls .......................4 1.4. Mainboard ..............................5 1.5. Control Functions .............................6 INSTALLATION ............................8 Unpacking ..............................8 External Connections ..........................8 2.2.1 Battery Power Supply ........................8 2.2.2... - Page 4 EN-2 T104 Series Indicators LEGAL FOR TRADE ..........................33 Settings ..............................33 Verification ............................. 33 Sealing ..............................34 MAINTENANCE ............................35 Cleaning ..............................35 Troubleshooting ............................. 36 TECHNICAL DATA ..........................37 Specifications ............................37 Table of Geo Code Values ........................39 APPENDICES ............................
-
Page 5: Introduction
T104 Series Indicators EN-3 1. INTRODUCTION This manual contains installation, operation, and maintenance instructions for T104P and T104S indicators. Please read it completely before installation and operation. 1.1. Safety Precautions Definition of Signal Warnings and Symbols Safety notes are marked with signal words and warning symbols. These show safety issues and warnings. -
Page 6: Overview Of Parts And Controls
EN-4 T104 Series Indicators 1.3. Overview of Parts and Controls Figure 1-1 T104P Indicator Item Description Item Description Front Housing Battery Cover Control Panel Mounting Bracket Rear Housing Power Cord Connector Screws (5) RS232 Connector Adjusting Knobs (2) Load Cell Connector... -
Page 7: Mainboard
T104 Series Indicators EN-5 1.4. Mainboard Figure 1-3 T104P Mainboard Item Description Item Description DC input (J1) Display board connector (J9) Dry cell input (J2) Load cell terminal block (J11) Ethernet kit / USB device kit connector (J5) Load cell connector (J12) -
Page 8: Control Functions
EN-6 T104 Series Indicators 1.5. Control Functions Figure 1-5 T104P Control Panel Figure 1-6 T104S Control Panel Button Primary Function On/Zero Print Function Tare (Short Press) If the terminal is Sends the current Initiates an Performs a tare off, press to power value to the RS232 application mode. - Page 9 T104 Series Indicators EN-7 Figure 1-7 Display Item Description Item Description NET symbol Pound, Ounce, Pound:Ounce symbols Center of Zero symbol Kilogram, Gram symbols Stable weight symbol Pieces symbol Negative symbol Percent symbol, Tonne symbol Preset tare symbol Battery symbol...
-
Page 10: Installation
EN-8 T104 Series Indicators 2. INSTALLATION Unpacking Unpack the following items: T104P or T104S indicator Mounting bracket Knobs (2) Quick installation guide Instruction manual Jumper connector for 4-wire load cell cable (supplied for stand-alone indicator) One ferrite core (supplied with some models for connecting load cell connector) External Connections 2.2.1... -
Page 11: Internal Connections
T104 Series Indicators EN-9 Internal Connections Some internal connections require to open the housing first. Therefore, please check the Opening the Housing section below before making connections. CAUTION: ELECTRICAL SHOCK HAZARD. REMOVE ALL POWER CONNECTIONS TO THE INDICATOR BEFORE SERVICING OR MAKING INTERNAL CONNECTIONS. THE HOUSING SHOULD ONLY BE OPENED BY AUTHORIZED AND QUALIFIED PERSONNEL, SUCH AS AN ELECTRICAL TECHNICIAN. - Page 12 EN-10 T104 Series Indicators Slightly push the end of the charging cover (circled) in the direction of the arrow and take it out. Remove the two screws on the charging board (circled) and take it out. Remove the five screws (circled) from the rear housing.
- Page 13 T104 Series Indicators EN-11 Open the rear housing. Close the rear housing, retighten the screws and re-install the lead-acid battery after finishing internal connections Note: The screws should be tightened to 1 N•m (8-9 in-lb) torque. 2.3.1.2 T104S Turn the two knobs (circled) on each side of the indicator to disassemble the bracket.
-
Page 14: Connecting The Cables
EN-12 T104 Series Indicators Open the rear housing. Close the housing and re-install the bolts after finishing internal connections Note: The bolts should be tightened to 2.5 N•m (20-25 in-lb) torque to ensure a watertight seal. 2.3.2 Connecting the cables 2.3.2.1 T104P... - Page 15 T104 Series Indicators EN-13 2.3.2.3 Load Cell Terminal Block Connection Proceed with the previous section, to connect the load cell terminal block, first locate it on the mainboard following the instruction in the previous two sections for the two models.
-
Page 16: T104P Rs232 Connection
EN-14 T104 Series Indicators 2.3.3 T104P RS232 Connection Connect the optional RS232 cable to the RS232 connector on the rear housing of the T104P indicator. Please refer to table 2-3 for the definition of each pin if needed. Table 2-3 RS232 Pins... -
Page 17: Mounting Bracket
T104 Series Indicators EN-15 Mounting Bracket Attach the bracket to a wall or table using fasteners (not supplied) that are appropriate for the type of mounting surface. The bracket will accommodate up to 6 mm (1/4”) diameter screws. Locate the mounting holes as shown in Figure 2-4 and 2-5. -
Page 18: Operation
EN-16 T104 Series Indicators 3. OPERATION Turning the Scale On/Off To turn the scale on, short press the On/Zero Off button. The scale performs a display test, momentarily displays the software version, the GEO value and then enters the last active weighing mode. -
Page 19: Counting Mode
T104 Series Indicators EN-17 Counting Mode Use this application to count the number of pieces on the pan based on an Average Piece Weight (APW). 3.3.1 Enter the Mode Press and hold the Mode button until is displayed. Release the Mode button. -
Page 20: Check
EN-18 T104 Series Indicators Check Use this application to compare the weight of items to a target weight range. The display color will change according to the comparing result: Red indicates over the target weight range Green indicates within the target weight range. -
Page 21: Application Settings
T104 Series Indicators EN-19 3.4.5 Application Settings The application can be customized for user preferences. Please refer to Application Settings section in Weighing Mode for details about how to enter application settings. The Check configurations are defined below (defaults in Bold). -
Page 22: View Totalization Result
EN-20 T104 Series Indicators 3.5.4 View Totalization Result When there is no weight on the pan, press the Function button to view the result. The result includes the number of samples, the total weight, the average weight, the minimum weight, the maximum weight and the difference in weight (the maximum weight minus the minimum weight). -
Page 23: Application Settings
T104 Series Indicators EN-21 3.5.7 Application Settings The application can be customized for user preferences. Please refer to Application Settings section in Weighing Mode for details about how to enter application settings. The Totalization Configurations are defined below (defaults in Bold). -
Page 24: Menu Settings
EN-22 T104 Series Indicators 4. MENU SETTINGS The User Menu allows the customizing of scale settings. Note: Sub-menu for options (USB, Ethernet and Print2 in the table below) will be active only when the specific board is installed. See their separate option instruction manuals for additional setting information. -
Page 25: Calibration Menu
T104 Series Indicators EN-23 The first digit is displayed flashing. Press the No button to increase the digit or press the Yes button to accept the digit and move to the next one. Note: press the Back button can decrease the digit. -
Page 26: Span Calibration [ ]
EN-24 T104 Series Indicators Span Calibration [ 4.2.2 Span calibration uses two calibration points to adjust the scale. The first point is the zero value where there is no weight on the scale. The second point is the Span value where a calibration mass is placed on the scale. -
Page 27: Geo Code Adjustment [ ]
T104 Series Indicators EN-25 Note: If after waiting for 40s the calibration is still not successful, is displayed for 3 seconds and the previous calibration data is restored. Repeat step 6 and 7. 10. The display shows , and then when the Linearity calibration is finished. -
Page 28: Setup Menu
EN-26 T104 Series Indicators Setup Menu Enter this menu to set scale parameters. Default settings are in bold. Sub-Menu (in Menu Sub-Menu Options Options (in segment) segment) Reset no, yes Capacity Unit kg, lb Range Single, Dual >|1|< Capacity 0.1-99999.9 >|1|<... -
Page 29: Readout Menu
T104 Series Indicators EN-27 Grad2 Set the second readability of the scale. Note: The value of graduation 2 must be larger than graduation 1, and it applies to capacity as well. The capacity and graduation value should be within the following range, or your setting will be... - Page 30 EN-28 T104 Series Indicators Stability Set the amount reading can vary before the stability symbol turns off. = 0.5 of a scale division = 1 scale division = 2 scale divisions = 5 scale divisions Zero Set the percentage of scale capacity that can be zeroed.
-
Page 31: Unit Menu
T104 Series Indicators EN-29 = power saving is enabled. = power saving is disabled. Set whether to enable California Energy Commission function. When enabled, the energy plan complies with the California Energy Commission regulation. = CEC is enabled. = CEC is disabled. -
Page 32: Communication
EN-30 T104 Series Indicators Communication Enter this menu to define external communication methods and to set printing parameters. Data may be output to either a printer or PC. Factory default settings are shown in bold. 4.6.1 RS232 Menu Enter this menu to define communication parameters. -
Page 33: Print Menu
T104 Series Indicators EN-31 Settings of A (a) to Z (z) are available. The default setting is W. Alternate Tare command Set the alternate command character for Tare. Settings of A(a) to Z(z) are available. The default setting is T. -
Page 34: Usb Configuration
EN-32 T104 Series Indicators Interval If Interval is selected, the sub-menu Time will display. = printing occurs at the defined time interval. Settings of 1 to 5000 seconds are available. Default is 1. Printing occurs at the defined time interval. -
Page 35: Legal For Trade
T104 Series Indicators EN-33 5. LEGAL FOR TRADE When the indicator is used in trade or a legally controlled application, it must be set up, verified and sealed in accordance with local weights and measures regulations. It is the responsibility of the purchaser to ensure that all pertinent legal requirements are met. -
Page 36: Sealing
EN-34 T104 Series Indicators Sealing After the scale has been verified, it must be sealed to prevent undetected access to the legally controlled settings. Refer to the illustrations below for sealing methods. Figure 5-3. T104P Wire Sealing Figure 5-4.T104P paper Sealing Figure 5-5. -
Page 37: Maintenance
T104 Series Indicators EN-35 6. MAINTENANCE CAUTION: DISCONNECT THE UNIT FROM THE POWER SUPPLY BEFORE CLEANING. Cleaning For T104P, the housing may be cleaned with a cloth dampened with a mild detergent if necessary. For T104S, use approved cleaning solutions for the stainless-steel Indicator housing and rinse with water. Dry thoroughly. -
Page 38: Troubleshooting
EN-36 T104 Series Indicators Troubleshooting TABLE 6-1 Troubleshooting SYMPTOM PROBABLE CAUSE (s) REMEDY EEP Error EEPROM Checksum Error Corrupted EEPROM data Unable to turn on the indicator. Power cord not plugged in or Check power cord connections. Make properly connected. -
Page 39: Technical Data
T104 Series Indicators EN-37 7. TECHNICAL DATA Specifications Equipment Ratings: Indoor use only Altitude: 2,000m Operating temperature: -10°C to 40°C Maximum relative humidity 80% for temperatures up to 31 °C decreasing linearly Humidity: to 50% relative humidity at 40°C. Electrical supply: 100 - 240V , 0.5A, 50/60Hz... - Page 40 EN-38 T104 Series Indicators Model T104S Construction 304 stainless steel housing, 304 stainless steel bracket Protection IP66 Maximum displayed resolution 1:30,000 Maximum approved resolution 1:6,000 Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric Weighing units Tonne) Modes Weighing, Counting, Check, Totalization Display 45 mm / 1.8 in digit height LCD display with 4-color backlight...
-
Page 41: Table Of Geo Code Values
T104 Series Indicators EN-39 Table of Geo Code Values TABLE 7-1 GEO CODES Elevation in meters 1300 1625 1950 2275 2600 2925 3250 1300 1625 1950 2275 2600 2925 3250 3575 Elevation in feet 1060 2130 3200 4260 5330 6400... - Page 42 EN-40 T104 Series Indicators FCC Supplier Declaration of Conformity Unintentional Radiator per 47CFR Part B Trade Name: B-TEK Model or Family identification: T104P, T104S Responsible Party – U.S. Contact Information: B-TEK Scales, LLC 1510 Metric Ave Canton, OH 44706 United States Phone: 330 471-8900 Web: www.b-tek.com...
-
Page 43: Appendices
T104 Series Indicators EN-41 8. APPENDICES Appendix A Commands listed in the following table will be acknowledged by the scale. The scale will return “ES” for invalid commands. Please add \r\n after each command to send. \r refers to \return; \n refers to \newline) - Page 44 EN-42 T104 Series Indicators Appendix B MT-SICS Commands Command Function LEVEL 0 Reset the scale Inquiry of all available SICS commands Inquiry of SICS level and SICS versions Inquiry of scale data Inquiry of scale software version Inquiry of serial number...
-
Page 45: Output Format
T104 Series Indicators EN-43 Output Format The default serial output format is shown below. Field: Polarity Weight Space Unit Stability Legend Length: Definitions: Polarity, “-” sign if negative, blank if positive. Weight, up to 6 numbers and 1 decimal, right justified, leading zero blanking. - Page 48 B-TEK Scales, LLC. 1510 Metric Avenue SW Canton, OH 44706, USA Tel: (330) 471-8900 Fax: (330) 471-8909 www.B-TEK.com *30728943* P/N 30728943 B Printed in China...
