BTEK T419S Service Manual page 105

Token Token Description of Value
T.x T.x.1
4 MOTN Motion
6 OVER Overload
7 UNDER Underload
8 CZ Center of Zero
12 CNT Count
38 INMOTM InMotion Time
107 CAT Accumulated Count Value Total
250 OUT1 Output 1 State: 0 = Not Active, 1 = Active
251 OUT2 Output 2 State: 0 = Not Active, 1 = Active
252 OUT3 Output 3 State: 0 = Not Active, 1 = Active
300 RTN Transaction Count
301 CON Consecutive Number (See note below)
304 B2H Binary to Hexadecimal
305 B2A Binary to ASCII
Status Byte
313 DIS
See Additional token tables on page 109
314 UTID Unique ID (Archive menu)
302 CKSM Checksum
Note:
Syntax for CON only:
Lower case [i] increments the number
Lower case [d] decrements the number
Upper case [R] resets the number to zero
T419S Indicator Service Manual
Name Value Data Type Parameter Name
T.x.2 T.x.3
Motion
Show Sign
Overload
Underload
Leading Zero
Center of Zero
Count
Width
InMotion Time
Count Total
Justification
OUT1
OUT2
OUT3
Transaction Count
Consecutive Number
Bin2Hex
Mode (Applies to tokens
Bin2Asc 304 and 305 only)
INTEGER
Status Binary Output
DSD Consec. Binary Conversion
Mode
Checksum
Applies to token 302 only
Optional Parameter Available Values
1 = Show - (default)
2 = Show +
p
3 = Show All
4 = Hide All
0 = None (default)
Z 1 = Leading Zeros
2 = Leading Spaces
1 - 127 Characters
W
Default is Configuration Dependent
1 = Right (default)
J
.2 = Left
1 = Stop (default)
M
2 = Start
1 = Truncate to 1-Byte Integer
2 = Truncate to 2-Byte Integer
B
3 = Truncate to 4-Byte Integer
4 = 4-Byte Floating Point
1 = As Binary (High Byte First)
c 2 = As Comma Separated Decimal in ASCII Format (High Byte First)
3 = As HEX in ASCII Format (High Byte First)
1 = Stop
2 = Transmit LSB First
3 = Transmit MSB First
4 = Send CRC 7-Bit
50 = Start CCITT
51 = Start SDLC / HDLC
52 = Start CRC 16 (0000)
53 = Start CRC 12
M 54 = Start IRCC 16
55 = Start IRCC 8
56 = Start Xmodem
57 = Start Sum 16
58 = Start Sum 8
59 = Start CRC 16 (FFFF)
60 = Start Inverse IRCC 8
61 = Start Sum 16 (W/O Twos)
62 = BCC
