- Page 1 Umbra Legacy User Guide Umbrella Mesh Network, LLC 510 W. Amador Ave., Las Cruces, NM 88005 (855) 602-5276 Ben@umbrellameshnetwork.com...
-
Page 2: Table Of Contents
Umbra Legacy User guide - Brought to you by Umbrella Mesh Network Table of Contents Introduction Indicator Lights Function Keys Sound Indicators WARNING Enroll/Delete remote Keyfob/Keypad Enroll/Delete Wireless Detector Enroll/Delete RFID Prox Tag/Card Enroll/Delete Wireless Siren Factory Default Zone Type Reference Table Umbrella Mesh Network, LLC 510 W. -
Page 3: Introduction
User guide - Brought to you by Umbrella Mesh Network This guide is to be used for a further understanding and some programming of the Umbra Legacy panel. The Quick Guide is available from www.umbrellameshnetwork.com and should be used for daily use. -
Page 4: Indicator Lights
Umbra Legacy User guide - Brought to you by Umbrella Mesh Network Indicator Lights • The meaning of the indicator lights is as follows Light on Light off Fast flashing Slow flashing Panelor detector Battery AC power power battery low power... -
Page 5: Function Keys
Umbra Legacy User guide - Brought to you by Umbrella Mesh Network Function Keys • The use of the function keys is as follows Away Arm • Press and hold for 3 seconds to activate Away arm function • This function is to be used when there will be no-one in the property and with all doors and windows closed. -
Page 6: Sound Indicators
Brought to you by Umbrella Mesh Network Sound Indicators • The Umbra Legacy panel has a number of sound indications to inform the user via an audible prompt of the reaction of the panel to certain functions. These are listed below. 1 Short “Di”... -
Page 7: Warning
Umbra Legacy User guide - Brought to you by Umbrella Mesh Network Caution! The following pages are instructions for adding and removing devices. Device changes should only occur after contacting your Security Alarm Service Provider. Umbrella Mesh Network, LLC 510 W. Amador Ave., Las Cruces, NM 88005 (855) 602-5276 Ben@umbrellameshnetwork.com... -
Page 8: Enroll/Delete Remote Keyfob/Keypad
Enroll Remote Keyfob—8 available slots • With the Umbra Legacy panel in the disarmed state, press and hold the “Enroll” button for 3 seconds. The panel will emit the “correct operation” short “Di” and the display will flash “E1” if the slot is availa- ble. -
Page 9: Enroll/Delete Wireless Detector
Enroll Wireless Detector—32 zone slots available • With the Umbra Legacy panel in the disarmed state, press and hold the “Enroll” button for 3 seconds. The panel will emit the “correct operation” short “Di” and then press the “Enroll” button again to get to the Zone Slots. -
Page 10: Enroll/Delete Rfid Prox Tag/Card
Enroll RFID Prox Tag/Card—8 slots available • With the Umbra Legacy panel in the disarmed state, press and hold the “Enroll” button for 3 seconds. The panel will emit the “correct operation” short “Di” and then press the “Enroll” button again twice to get to the RFID Prox Slots. -
Page 11: Enroll/Delete Wireless Siren
Enroll Wireless Siren—1 slot available • With the Umbra Legacy panel in the disarmed state, press and hold the “Enroll” button for 3 seconds. The panel will emit the “correct operation” short “Di” and then press the “Enroll” button again 3 times to get to the Siren slot. -
Page 12: Factory Default
Factory Default • With the Umbra Legacy panel fully powered down, apply power via the 12V DC port on the back while holding together the “Enroll” button and the “SOS” Button together for a full 15 seconds to perform a full factory default. -
Page 13: Zone Type Reference Table
Brought to you by Umbrella Mesh Network Zone Types • The Umbra Legacy panel has a number of different Zone types that indicate the function of the zone. These are listed below. • Zone types need to be programmed via App control using UmbraAlarm...
