- Page 1 DDA108A-BP SDI distribution amplifier with relay bypass Crystal Vision Ltd., Lion Technology Park, Station Road East, Whittlesford, Cambridge, CB22 4WL, England. E-mail: sales@crystalvision.tv Website: www.crystalvision.tv Tel: +44(0) 1223 497049 Fax: +44(0) 1223 497059...
-
Page 2: Table Of Contents
DDA108A-BP Crystal Vision Contents Introduction Card edge operation Hardware installation Universal rear connectors Rear module connections with RM01 Rear module connections with RM38 Rear module connections with RM18 Rear module connections with RM02 General purpose interface 4U frame GPI Connections... -
Page 3: Introduction
DDA108A-BP non reclocking ASI/SDI distribution amplifier The DDA108A-BP may be used with the RM01 single slot rear connector, the RM02 quadruple slot rear connector and the RM18 double slot rear connector. If relay bypass is required the rear module used is the RM38. A single slot rear connector provides five equalised outputs and three extra outputs are available with the double and quadruple slot connectors. -
Page 4: Card Edge Operation
Crystal Vision Card edge operation 2 Card edge operation The front edge of the DDA108A-BP card provides power rail monitoring and signal status. DDA108A-BP front edge view Location/colour Meaning when lit Green Valid DVB-ASI/SDI input detected. INPUT Green Power supply voltage present. -
Page 5: Hardware Installation
The DDA108A-BP may be used with the RM01 and RM38 single slot rear connector, the RM02 quadruple slot rear connector and the RM18 double slot rear connector. -
Page 6: Rear Module Connections With Rm38
8 connections available • Card fits in upper slot • No card fits in lower slot I/O assignment DVB-ASI/SDI Input DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DDA108A-BP User Manual R1.0 25/02/10... -
Page 7: Rear Module Connections With Rm02
Card 3 fits in slots 4, 8 and 12 • No card fits in 3, 7 or 11 I/O assignment DVB-ASI/SDI Input SDI IN DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output DVB-ASI/SDI Output 8/IN2 DDA108A-BP User Manual R1.0 25/02/10... -
Page 8: General Purpose Interface
10 (1) 11 (1) 19 (1) 20 (1) 21 (2) 22 (2) 3 (3) 12 (3) 22 (3) 21 (3) 12 (4) 13 (4) 10 (3) 11 (3) 19 (3) 20 (3) 21 (4) 22 (4) DDA108A-BP User Manual R1.0 25/02/10... -
Page 9: Frame Gpi Connections
6 in each case and +5V @500mA is pin 15 on Remote 2. The +5V output is protected by self-resetting thermal fuses, which limit the total output current available from Remotes 1-4 to approximately 1A. DDA108A-BP User Manual R1.0 25/02/10... -
Page 10: Frame Gpi Connections
Remote 2: 26 way high-density D-Type male plugs and frame ground is pin 6 and +5V @500mA is pin 15 The +5V output is protected by self-resetting thermal fuses, which limit the total output current available from Remotes 1-2 to approximately 1A. DDA108A-BP User Manual R1.0 25/02/10... -
Page 11: Problem Solving
If required, the card may be reset by simply removing the rack power and re-applying power after a few seconds or by removing the card from the rack and then re-inserting the card It is safe to re-insert the card whilst the rack is powered DDA108A-BP User Manual R1.0 25/02/10... -
Page 12: Specification
Outputs Number and type: 8 non re-clocked Each will drive >250m Belden 8281 or equivalent Status monitoring LED display Front of card edge visual monitoring with LED indicators to indicate: PSU rail present, Input present DDA108A-BP User Manual R1.0 25/02/10...
