MODEL #
CM3351PT-5PK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips Screwdriver
(Not Included)
Wrench 8mm
(Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3351PT-5PK
Summary of Contents for Furniture of America CM3351PT-5PK
- Page 1 MODEL # CM3351PT-5PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) Wrench 8mm (Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 1 1...
- Page 5 TABLE CM3351PT-5PK #1 1pc #2 4pcs #3 1pc Table Leg Table Top Apron #4 1pc #5 2pcs Connect Board Middle Shelf #A 12pcs #B 12pcs #C 28pcs Lock Washer Ø 1/4" Flat Washer Ø 1/4" Bolt Ø 1/4"X1-15/16" #F 2pcs...
-
Page 6: Exploded View
ASSEMBLY INSTRUCTIONS Exploded View Prepare 8 bolts assembly by inserting lock washer (#B), then flat washer Part #2 x4pcs (#C) onto bolts (#A). Align legs (#2) to the holes of the apron (#3) and Part #3 x1pc middle shelf (#4). Secure with bolts (#A). Part #4 x1pc Hardware... - Page 7 ASSEMBLY INSTRUCTIONS Part #5 x2pcs Hardware #A x4pcs Hardware #B x4pcs Hardware #C x4pcs Prepare 4 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align connect board (#5) to the holes on the top of the legs (#2).
- Page 8 CHAIR CM3351PT-5PK #1 1pc x 4 # 3 1pc x4 # 4 1pc x4 # 5 2pcs x4 # 2 1pc x4 Chair Back Cushion Seat Leg(L&R) Front Stretcher Stretcher(L&R) # A 4pcs x4 #B 2pcs x4 #C 6pcs x4 #D 6pcs x4 Bolt Ø...
- Page 9 ASSEMBLY INSTRUCTIONS Exploded View Prepare 2 bolts assembly by inserting lock Part #1 x1pc Part washer (#C), then flat washer (#D) onto bolts #2 x1pc (#B). Align chair seat (#2) to the holes of the Hardware #B x2pcs chair back (#1). Secure the middle two holes Hardware #C x2pcs with bolts (#B).
- Page 10 ASSEMBLY INSTRUCTIONS Hardware #A x4pcs Hardware #C x4pcs Prepare 4 bolts assembly by Hardware #D x4pcs inserting lock washer (#C), then flat washer (#D) onto bolts (#A). Secure corner holes of chair seat (#2) with bolts (#A). 1) Align the front legs (#3L/R) to the holes of the chair seat (#2). Insert flat washer (#J), Part #3 x1pc then lock washer (#I) onto threaded bolts of legs (#3L/R).
- Page 11 ASSEMBLY INSTRUCTIONS Secure stretchers (#4,5) with screws (#F). Hardware #F x6pcs 11 / 11...
