MODEL #
CM3305OT
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - Persons
Recommended
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3305OT
Summary of Contents for Furniture of America CM3305OT
- Page 1 MODEL # CM3305OT Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - Persons Recommended The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 2 / 8...
- Page 3 3 / 8...
- Page 4 4 / 8...
- Page 5 TABLE CM3305OT #1 1pc #2 1pc #3 4pcs Pedestal Table Leg with Leveler Table Top #4 1pc #5 1pc #6 1pc #7 1pc Upper Base Lower Center Top Mounting Plate Plate Base Plate #A 20pcs #B 20pcs #C 12pcs Spring Washer 5/16"...
- Page 6 ASSEMBLY INSTRUCTIONS Align legs (#3) to the pedestal (#2), then secure by using hex nuts (#C) with washers (#B,A). Part #2 x1pc Part #3 x4pcs Hardware #A x8pcs Hardware #B x8pcs Hardware #C x8pcs Remove the plastic cover from the Pedestal and Footings.
- Page 7 ASSEMBLY INSTRUCTIONS Align mounting plate (#4) to the crossbars (#5,6), then secure by using bolts (#E) with washers (#B,A). Part #4 x1pc Hardware #A x4pcs Hardware #B x4pcs Hardware #E x4pcs Part #7 x1pc Unlock the Cam Lock under the table before Side Leaf assembled then lock it.
- Page 8 ASSEMBLY INSTRUCTIONS Hardware #A x4pcs Hardware #B x4pcs Hardware #C x4pcs Align table (#1) with mounting plate (#4) to pedestal (#2), then secure by using hex nuts (#C) with washers (#B,A). Assembly Completed !! 8 / 8...
