VERSION
# 20-06-0 9
1 / 7
MODEL #
CM3350SC-2PK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3350SC-2PK
Summary of Contents for Furniture of America CM3350SC-2PK
- Page 1 MODEL # CM3350SC-2PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. VERSION...
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 7...
- Page 5 SIDE CHAIR CM3350SC-2PK #1 1pcx2 #2 1pcx2 #3 2pcsx2 Chair Back Cushion Seat Front Leg #A 2pcsx2 #B 4pcsx2 #C 4pcsx2 #D 10pcsx2 #E 10pcsx2 Bolt Ø5/16" x 1-3/4" Bolt Ø5/16" x 2-3/8" Bolt Ø5/16" x 3" Lock Washer Ø5/16"...
- Page 6 ASSEMBLY INSTRUCTIONS 1. Prepare 2 bolt assemblies by first inserting a lock washer (#D) onto the bolt (#A) then a flat washer (#E) onto that same bolt (#A). 2. Insert and align the cushion (#2) to the holes along the chair back Parts #1 x 1pc (#1).
- Page 7 ASSEMBLY INSTRUCTIONS 1. Prepare 4 bolt assemblies by first inserting a lock washer (#D) onto the bolt (#B) then a Parts flat washer (#E) onto that same bolt (#B). #3 x 2pcs 2. Align the legs (#3) to the front corners, then Hardware #B x4pcs insert the bolt assemblies and secure.
